9.AD0 Cembre EWO IP66 Grey Blank Grommet For Split Cable Entry Systems

Why Choose the Cembre EWO 9.AD0 IP66 Grey Blank Grommet

The Cembre 9.AD0 is a grey blank grommet for EWO split cable entry systems. It occupies one small grommet position to maintain sealing and layout when a cable aperture is not required, helping you preserve the enclosure’s IP66 integrity and a clean, professional finish.

Part of the EWO modular platform, the 9.AD0 uses the Type A small format and simply clips into the frame from above during final assembly. Swap it for a drilled grommet later if a new cable needs routing, with no rework to the panel cut out.

Key Features

• Blank (0 hole) grommet to close unused positions and maintain sealing.
• Type A small size, nominal module 20 × 20.6 mm.
• Compatible with all EWO split frames using Type A grommets.
• Supports system IP66 protection when used with EWO frames.
• Available in grey and black options in the range.
• Part of a family covered by UL (cURus) and RINA approvals.

Technical Specifications

• Manufacturer: Cembre
• Series: EWO split cable entry system
• Model: 9.AD0
• Function: Type A small blank grommet (0 hole)
• Module size: 20 × 20.6 mm (Type A)
• Material: Thermoplastic elastomer (TPE)
• Colour: Grey
• System ingress protection: IP66 when installed in a compliant EWO frame with overmoulded seal
• Typical operating temperature (system): frame −40 to +140 °C; grommets suitable for industrial environments
• Approvals: UL (cURus) and RINA across the EWO family
• Notes: Use to blank unused apertures; can be replaced later with drilled grommets from the 9.A* range.

Certifications

EWO grommets are part of a certified system including UL (cURus) and RINA approvals. The frames provide IP66 sealing via an overmoulded gasket with no external seal required.

Comparison and Selection Notes

Choose 9.AD0 to blank off one Type A position. For single cable grommets select 9.A1D* (1 hole, 1–16.5 mm), for two cables 9.A2D*, or for four cables 9.A4D*, all in the same 20 × 20.6 mm Type A footprint.

Frequently Asked Questions

• What is the 9.AD0 used for
• Which frames does it fit
• Does using a blank maintain IP66
• Can I swap it later for a drilled grommet

Applications

• Keeping unused entries sealed during commissioning or phased installations.
• Futureproofing panels where additional cables may be added later.
• Tidy cable management in control cabinets, machinery and OEM equipment.

Trusted By Panel Builders

"Handy for spare ways and change control. Keeps everything sealed until we need the slot." Panel Builder, UK
