9000.16/5 Cembre EWO IP66 Black Rectangluar Split Cable Entry Systems

Why Choose the Cembre 9000.16/5 Split Cable Entry Frame?

The Cembre 9000.16/5 is a high-capacity EWO rectangular split cable entry frame engineered for routing pre-terminated cables into electrical enclosures without disconnecting existing connectors. Designed to accommodate four small cable grommets and one large cable grommet, it offers outstanding flexibility for mixed cable sizes while maintaining reliable IP66 ingress protection through its integrated overmoulded sealing system.

Manufactured from glass fibre reinforced PA6.6, the 9000.16/5 combines exceptional mechanical strength with long service life in demanding industrial environments. The innovative Plug & Fix opening mechanism allows installers to fit the frame around pre-installed cables, reducing installation time and eliminating unnecessary cable re-termination.

As part of the Cembre EWO (Easy Wire Organizer) range, the 9000.16/5 provides dependable cable sealing, effective strain relief and organised cable management for industrial automation, machinery, switchgear and electrical control panels.

Key Advantages

• Designed for pre-terminated cable installations.
• Accepts 4 small and 1 large EWO cable grommet.
• Integrated overmoulded seal delivers IP66 protection.
• Plug & Fix split-frame design enables rapid installation.
• Glass fibre reinforced PA6.6 construction for excellent durability.
• Silicone-free and halogen-free design.
• Compact design removes the need for an additional sealing gasket.

Key Features

• Manufacturer: Cembre
• Part Number: 9000.16/5
• Series: EWO Easy Wire Organizer
• Product Type: Rectangular split cable entry frame
• Capacity: 4 small + 1 large cable grommet.
• Integrated TPE overmoulded sealing gasket.
• Designed for pre-assembled cable installations.
• Suitable for industrial control panels and electrical enclosures.

Technical Specifications

• Manufacturer: Cembre
• Series: EWO
• Model: 9000.16/5
• Product Type: Split cable entry frame
• Material: Glass fibre reinforced PA6.6
• Seal Material: Overmoulded TPE elastomer
• Ingress Protection: IP66
• Overall Dimensions: 120 × 61 × 19.5 mm
• Panel Cut-out: 86 × 36–46 mm
• Fixing Hole Diameter: 5.5 mm (M5 fixing)
• Operating Temperature: -40°C to +140°C
• Colour: Black (RAL 9005)
• Grommet Capacity: 4 small + 1 large grommet
• Weight: Approx. 60 g
• Compliance: CE, UKCA, UL, RINA, EN 62444, UL94 V0

Flexible Cable Entry for Mixed Cable Sizes

The Cembre 9000.16/5 is designed for applications where both small signal cables and larger power cables need to pass through the same enclosure. Its split-frame construction allows installation after connectors have already been fitted, protecting valuable cable assemblies while significantly reducing installation time.

The integrated Stop Plinth technology prevents excessive compression of the sealing element, ensuring dependable IP66 protection against dust and water ingress throughout the product's service life. Combined with its robust construction, the frame is ideally suited to industrial automation and machine-building applications.

Typical Applications

• Industrial automation systems.
• PLC and electrical control panels.
• Machine building.
• OEM equipment manufacturing.
• Switchgear and distribution cabinets.
• Robotics and conveyor systems.
• Retrofit installations using mixed-size pre-terminated cables.

Trusted for Industrial Cable Management

Cembre EWO cable entry systems are trusted worldwide by panel builders, OEMs and automation engineers for delivering fast installation, dependable environmental sealing and professional cable management solutions in demanding industrial environments.
