9000.24/4 Cembre EWO IP66 Black Rectangluar Split Cable Entry Systems

Why Choose the Cembre EWO 9000.24/4 IP66 Rectangular Split Cable Entry Frame

The Cembre EWO 9000.24/4 is a black rectangular split cable entry frame designed to simplify installation of pre-terminated cables into control panels and enclosures. Its glass-fibre reinforced PA6.6 body and overmoulded inner seal deliver reliable IP66 ingress protection without needing an external gasket, keeping panels neat and protected.

Utilising Cembre’s Plug & Fix quick-open system along with the Stop Plinth sealing design, the 9000.24/4 enables cables to be routed first and the frame closed afterward, reducing installation time and damage risk. Silicone-free, halogen-free construction and UL 94 V0 flame rating make it suitable for demanding industrial environments.

Key Features

• Rectangular split frame with 4 small grommet positions.
• IP66 ingress protection from integrated overmoulded seal.
• Glass-fibre reinforced PA6.6 body with TPE seal.
• Plug & Fix mechanism allows fast retrofit around pre-terminated cables.
• Stop Plinth seal protection helps prevent over-compression.
• Silicone-free and halogen-free; flame-rated UL 94 V0.

Technical Specifications

• Manufacturer: Cembre
• Series: EWO Easy Wire Organiser
• Model: 9000.24/4
• Colour: Black
• Ingress protection: IP66
• Material: Glass-fibre reinforced PA6.6 with overmoulded TPE seal
• Operating temperature: Frame –40 to +140 °C, Grommets –40 to +100 °C
• Wall cut-out size: Approx. 118 mm × 36/46 mm
• Fixing hole centres: Approx. 136 mm × 32 mm
• Fixing holes: Ø 5.5 mm for M5 screws
• Grommet capacity: 4 small grommets (20.6 × 20 mm)
• Screw tightening torque: 2.2 N·m
• Compliance: EN 62444 for cable clamping
• Approvals: CE, UKCA, UL (UL50) Types 1, 12, 4X indoor; RINA; EN 45545-2; UV ISO 4892-2A; RoHS
• Notes: External seal not required; compatible with EWO interchangeable grommets.

Certifications

Verified to CE, UKCA, and UL (UL50) environmental ratings Types 1, 12, 4X indoor. Fire performance certified to EN 45545-2, UV resistance per ISO 4892-2A, RoHS compliant, and approved by RINA.

Comparison and Selection Notes

Use 9000.24/4 when you need four small grommet slots in a rectangular frame. For fewer slots consider 9000.16/2 or 9000.10/3. For higher density, choose 9000.16/5 or 9000.16/8. Square frames are available as 9000.Q/1 and 9000.Q/4.

Frequently Asked Questions

• What is the 9000.24/4 used for
• How does it achieve IP66 without an external seal
• What panel cut-out is required
• Which approvals does it carry
• Which grommets are compatible
• What screws and torque should I use

Applications

• Panel builders managing medium cable counts.
• Industrial control panels, automation cabinets, drives, and I/O modules.
• Enclosures needing neat pre-terminated cable entry with IP66 protection.
• Outdoor or demanding industrial environments requiring UV-resistance and compliance ratings.
