9.A1D16N Cembre EWO IP66 Black 1 hole 16 - 16.5mm cable clamp Grommet For Split Cable Entry Systems
MPN: 9.A1D16N
Alt. SKU: 3201866
Special Price
£1.72
£1.43
Regular Price
£2.28
9.A1D16N Cembre EWO IP66 Black 1 hole 16 - 16.5mm cable clamp Grommet For Split Cable Entry Systems is available to buy in increments of 10
Why Choose the Cembre EWO 9.A1D16N IP66 Black 1 Hole 16 - 16.5 mm Cable Clamp Grommet
The Cembre 9.A1D16N is a black single hole grommet from the EWO split cable entry system range. It is designed to route and seal a 16 - 16.5 mm cable, offering secure strain relief and maintaining the enclosure’s IP66 ingress protection for demanding electrical and industrial applications.
Built on the modular Type A format, this grommet clips directly into compatible EWO frames. It is fully interchangeable with other Type A modules, allowing you to adapt to future cabling requirements without modifying the enclosure cut out.
Key Features
- 1 hole for a single 16 - 16.5 mm cable.
- Provides strain relief and a long lasting seal.
- Type A module dimensions: 20 × 20.6 mm.
- Helps maintain IP66 protection when installed in an EWO frame.
- Fast clip in assembly, ideal for pre terminated cables.
- Black finish for discreet applications; grey variant also available.
Technical Specifications
- Manufacturer: Cembre
- Series: EWO split cable entry system
- Model: 9.A1D16N
- Function: Type A single hole cable clamp grommet
- Cable diameter range: 16 - 16.5 mm
- Module size: 20 × 20.6 mm
- Material: Thermoplastic elastomer (TPE)
- Colour: Black
- Ingress protection: IP66 (with EWO frame)
- Operating temperature: −40 to +140 °C
- Certifications: CE, UKCA, UL (cURus), RINA (system level)
- Notes: Interchangeable with blanks (9.AD0N/9.AD0), two hole (9.A2D*) and four hole (9.A4D*) Type A modules.
Certifications
The 9.A1D16N is part of the certified EWO modular platform. When installed in a compliant frame, it supports IP66 sealing. The EWO system carries CE, UKCA, UL (cURus) and RINA approvals.
Comparison and Selection Notes
Choose 9.A1D16N for sealing one 16 - 16.5 mm cable in black. For the grey version, select 9.A1D16. For two or four cables in the same footprint, use 9.A2D* or 9.A4D*. To blank unused slots, choose 9.AD0N (black) or 9.AD0 (grey).
Frequently Asked Questions
- What is the 9.A1D16N used for
- Which frames does it fit
- Does it maintain IP66
- Can it be interchanged with other grommets
Applications
- Sealed routing of 16 - 16.5 mm power and control cables.
- Industrial automation panels, cabinets, and switchgear.
- OEM assemblies requiring modular, sealed cable entry systems.
Trusted By Panel Builders
"Perfect for larger diameter cables, this grommet keeps panels sealed and secure while being easy to fit." Panel Builder, UK
Frequently Asked Questions
What is the 9.A1D16N used for
A black Type A grommet designed to route and seal one 16 - 16.5 mm cable in an EWO split frame, ensuring IP66 protection.
Which frames does it fit
It fits all EWO frames compatible with Type A grommets, including rectangular, reduced rectangular, and square frames.
Does it maintain IP66
Yes. Installed in a compliant EWO frame with integrated seal, the 9.A1D16N maintains IP66 ingress protection.
Can it be interchanged with other grommets
Yes. It can be exchanged with other Type A grommets, including blanks, two hole, or four hole versions.
| Manufacturer Part Number | 9.A1D16N |
|---|---|
| Alternative Product SKU | 3201866 |
| Manufacturer | Cembre |
| Degree of protection (IP) | IP66 |
| Colour | Black |
| Min Operating Temperature(Deg. C) | -40 |
| Max. operating temperature(Deg. C) | 100 |
| Material | TPE elastomer |
| Silicone-free | Yes |
| Halogen free | Yes |
| Number of Holes | 1 |
| Packed Quantity | 10 |
| Height | 20.6mm |
| Width | 20mm |
| Depth | 17.5mm |
