Mersen Surge Protector Type 2 SPD 3 Pole 1000 Volt D/C 20KA Y-P Volt Remote Indication
MPN: 83020141
Alt. SKU: STPT2-40K1000V-YPVM
Special Price
£142.55
£118.79
Regular Price
£190.07
Why Choose the Surge Protection Device Type 2, 40kA Imax (8/20), Y PV, 1000Vdc, 3 Poles, Pluggable, 3 Modules, Remote Indication STPT2-40K1000V-YPVM?
Engineered for photovoltaic installations up to 1000V DC, this robust Type 2 surge protection device safeguards sensitive PV equipment against transient overvoltages, delivering a maximum discharge current of 40kA (8/20 μs). Its Y PV configuration ensures maximum protection and reliability across 3 poles, making it ideal for commercial and industrial solar applications.
The pluggable, 3-module design ensures rapid installation and straightforward maintenance, while integrated remote indication provides immediate status monitoring for efficient system management. Depend on the STPT2-40K1000V-YPVM to enhance uptime, safety, and longevity in demanding photovoltaic systems.
Technical Specifications
- Item number: 83020141
- Catalogue No: STPT2-40K1000V-YPVM
- Description: Surge Protection Device Type 2, 40kA Imax (8/20), Y PV, 1000Vdc, Photovoltaic, 3 Poles, Pluggable, 3 Modules, Remote indication
- EAN/UPC Code: 8435297849339
- RoHS Compliant: Yes
- IEC SPD Type: Class II
- UL SPD Type: Type 2 Component Assembly
- Format: Pluggable
- AC or DC: DC
- Nominal Discharge Current (In) (8/20): 20 kA
- Max Discharge Current : Imax (8/20): 40 kA
- Protection Modes: L+/PE, L-/PE, L+/L-
- System Configuration: YPV
- Short Circuit Withstand (ISCPV): 10 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace) Microswitch
- Torque Rating: 3 Nm
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Up at In (L-PE): ≤4 kV
- MCOV DC+ DC-: 1000 V
- MCOV DC+ G: 1000 V
- MCOV DC- G: 1000 V
- VPR DC+ DC-: 3000 V
- VPR DC+ G: 3000 V
- VPR DC- G: 3000 V
- Replacement Plug L1: 83020006
- Product Width: 54 mm
- Product Length: 70 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.364 kg
- Sell Pack Width: 63 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Photovoltaic & Energy Storage SPDs
- Product Weight: 0.324 kg
Product Code: 83020141
Key Benefits
- High surge current capacity of 40kA (8/20 μs) for superior protection.
- Y PV system configuration ensures comprehensive 3-pole protection.
- Pluggable 3-module design allows for quick installation and easy maintenance.
- Integrated remote indication system for real-time status monitoring.
- Robust housing material (PA66 CT1) for durability in harsh environments.
- Compliant with IEC Class II and UL Type 2 standards for safety and reliability.
Compatibility
This surge protection device is compatible with photovoltaic systems operating up to 1000 V DC, suitable for commercial and industrial solar installations. It integrates seamlessly with standard PV arrays requiring Type 2 surge protection and supports systems configured in Y PV topology.
Applications
- Commercial and industrial photovoltaic power systems.
- Solar energy installations requiring DC surge protection.
- Energy storage systems with photovoltaic integration.
- Systems needing remote status monitoring for surge protection devices.
Frequently Asked Questions
What is the maximum voltage this SPD can handle?
The device is designed for photovoltaic systems up to 1000 V DC nominal voltage.
Does this SPD provide remote indication?
Yes, it includes an integrated remote indication system with a green (OK) / not green (replace) microswitch.
Is this surge protector suitable for AC systems?
No, this model is specifically designed for DC photovoltaic systems.
Can the modules be replaced individually?
Yes, the pluggable 3-module design allows for easy replacement of individual modules.
Common Search Terms
Surge protection device, SPD Type 2, photovoltaic surge protector, 1000V DC SPD, 40kA surge arrester, pluggable SPD, remote indication SPD, solar panel surge protection, Y PV surge protector, DC surge protection device.
| Manufacturer Part Number | 83020141 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297849339 |
| Height | 70mm |
| Width | 54mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 3 Pole |
| Voltage | 1000VDC |
| Maximum Continuous Voltage | 1060V |
| Nominal Discharge Current | 20Ka |
| Remote Indication | Yes |
| System Type | Y-PV |
| Alternative Product SKU | STPT2-40K1000V-YPVM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
