Mersen Surge Protector Type 2 SPD 1 Pole 277 Volt 20KA L-N Remote Indication
MPN: 83020109
Alt. SKU: STPT2-40K320V-1PM
This product is discontinued. Please view this replacement item.
Why Choose the STPT2-40K320V-1PM Surge Protection Device?
Engineered for robust protection, the STPT2-40K320V-1PM delivers reliable Type 2 surge suppression with a maximum discharge current of 40kA (8/20μs) for single-phase 277V AC systems. Its 1-pole, L-N configuration ensures critical defence against transient overvoltages, safeguarding sensitive equipment and infrastructure.
This compact, 1-module solution features a pluggable design for simple replacement and integrates remote indication capability for straightforward monitoring. Ideal for industrial and commercial panels requiring guaranteed surge resilience and maintenance efficiency.
Technical Specifications
- Item number: 83020109
- Catalogue No: STPT2-40K320V-1PM
- Description: Surge Protection Device Type 2, 40kA Imax (8/20), 1Ph, 277V, L-N, 1 Pole, Pluggable, 1 Module, Remote indication
- EAN/UPC Code: 8435297850670
- RoHS Compliant: Yes
- IEC SPD Type: Class II
- UL SPD Type: Type 2 Component Assembly
- Format: Pluggable
- Nominal Operating Volt Rating (Un): 277
- AC or DC: AC
- Nominal Discharge Current (In) (8/20): 20 kA
- Max Discharge Current : Imax (8/20): 40 kA
- Protection Modes: L - N / L-PE / N-PE
- System Configuration: TNS, TNC, TT (only L-N)
- Short Circuit Withstand (ISCCR): 25 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace) Microswitch
- Number of Poles: 1-pole
- Torque Rating: 3 Nm
- Max. Back-Up Fuse: 125 A [gG]
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Installation Mounting: DIN rail
- VPR L-N: 1000 V
- Replacement Plug L1: 83020003
- Product Width: 18 mm
- Product Length: 70 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.146 kg
- Sell Pack Width: 24 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.123 kg
Product Code: 83020109
Key Benefits
- Provides high surge current capacity of 40kA for superior protection.
- Compact 1-module design saves panel space and simplifies installation.
- Pluggable format allows for quick and easy replacement without rewiring.
- Remote indication feature enables convenient status monitoring.
- Compatible with various system configurations including TNS, TNC, and TT.
- Durable PA66 CT1 housing ensures long-term mechanical and environmental resistance.
Compatibility
The STPT2-40K320V-1PM is compatible with single-phase 277V AC systems and supports system configurations TNS, TNC, and TT (only L-N). It fits standard DIN rail mounting and is suitable for integration in industrial and commercial electrical panels requiring Type 2 surge protection.
Applications
- Industrial control panels
- Commercial building electrical distribution
- Protection of sensitive electronic equipment
- Renewable energy installations
- Infrastructure and automation systems
Frequently Asked Questions
What is the maximum surge current this device can handle?
The STPT2-40K320V-1PM can handle a maximum discharge current (Imax) of 40 kA (8/20μs waveform).
Is remote indication supported on this SPD?
Yes, it includes a remote indication system with a green (OK) / not green (replace) microswitch for status monitoring.
Can this device be installed on a DIN rail?
Yes, the device is designed for DIN rail mounting for easy installation in electrical panels.
What is the nominal operating voltage?
The nominal operating voltage (Un) is 277V AC.
Common Search Terms
Type 2 surge protector, 40kA surge protection device, 277V SPD, pluggable surge protector, DIN rail SPD, single-phase surge protection, remote indication SPD, industrial surge protector
| Manufacturer Part Number | 83020109 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297850670 |
| Height | 70mm |
| Width | 18mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 1 pole |
| Voltage | 277V |
| Maximum Continuous Voltage | 320V |
| Nominal Discharge Current | 20Ka |
| Remote Indication | Yes |
| System Type | L-N |
| Alternative Product SKU | STPT2-40K320V-1PM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
