Mersen Surge Protector Type 1+2 SPD 1 Pole 120 Volt 20KA L-N Remote Indication
MPN: 83120101
Alt. SKU: STPT12-12K150V-1PM
Special Price
£92.17
£76.81
Regular Price
£124.72
Why Choose the Surge Protection Device Type 1+2 STPT12-12K150V-1PM?
This Type 1+2 surge protection device delivers robust protection for single-phase 120V AC networks, meeting stringent IEC standards. With a high Iimp rating of 12.5kA (10/350 µs), it offers reliable defence against direct and indirect lightning strikes as well as transient overvoltages.
Engineered as a compact, pluggable single-pole solution, it enables quick installation and straightforward maintenance. The integrated remote indication provides real-time status monitoring, ensuring operational safety and system uptime across critical electrical infrastructures.
Technical Specifications
- Item number: 83120101
- Catalogue No: STPT12-12K150V-1PM
- Description: Surge Protection Device Type 1+2, 12.5kA Iimp (10/350), 1Ph, 120V, L-N, 1 Pole, Pluggable, 1 Module, Remote indication
- EAN/UPC Code: 8435297851288
- RoHS Compliant: Yes
- IEC SPD Type: Class I+II
- Format: Pluggable
- Nominal Operating Volt Rating (Un): 120
- AC or DC: AC
- Max Discharge Current : Imax (8/20): 50 kA
- Protection Modes: L - N / L-PE / N-PE
- System Configuration: TNS, TNC, TT (only L-N)
- Lightning Impulse Current (10/350) (LIMP): 12.5 kA
- Short Circuit Withstand (ISCCR): 25 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace) Microswitch
- Number of Poles: 1-pole
- Torque Rating: 3 Nm
- Max. Back-Up Fuse: 200 A [gG]
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Installation Mounting: DIN rail
- Replacement Plug L1: 83120001
- Product Width: 18 mm
- Product Length: 76 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.168 kg
- Sell Pack Width: 24 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.148 kg
Product Code: 83120101
Key Benefits
- High lightning impulse current rating (12.5 kA) ensures superior protection against surges.
- Compact and pluggable design allows for easy installation and maintenance.
- Integrated remote indication system for real-time status monitoring.
- Complies with IEC Class I+II standards for reliable surge protection.
- Suitable for multiple system configurations including TNS, TNC, and TT.
- Robust housing material (PA66 CT1) for enhanced durability.
Compatibility
This surge protection device is compatible with single-phase 120V AC electrical systems configured as TNS, TNC, and TT (only L-N). It integrates seamlessly with DIN rail mounting systems and supports backup fuses up to 200 A [gG]. Replacement plugs are available for easy servicing.
Applications
- Protection of residential and commercial single-phase electrical installations.
- Surge protection for critical infrastructure and industrial control panels.
- Lightning and transient overvoltage defence in power distribution systems.
- Use in systems requiring remote status indication for maintenance efficiency.
Frequently Asked Questions
What types of surges does this device protect against?
The device protects against direct and indirect lightning strikes as well as transient overvoltages commonly found in single-phase 120V AC networks.
Can this SPD be used in three-phase systems?
No, this specific model is designed for single-phase systems only.
How is the status of the SPD indicated?
The device features a green/not green microswitch indication system and remote indication capability for real-time status monitoring.
What is the maximum backup fuse rating supported?
The SPD supports a maximum backup fuse rating of 200 A [gG].
Common Search Terms
surge protection device, SPD, Type 1+2 SPD, 120V surge protector, lightning protection, pluggable SPD, single-pole surge protector, IEC Class I+II SPD, DIN rail SPD, remote indication surge protector
| Manufacturer Part Number | 83120101 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297851288 |
| Height | 76mm |
| Width | 18mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 1 pole |
| Voltage | 120V |
| Maximum Continuous Voltage | 150V |
| Nominal Discharge Current | 20Ka |
| Remote Indication | Yes |
| System Type | L-N |
| Alternative Product SKU | STPT12-12K150V-1PM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
