Mersen Surge Protector Type 2 SPD 1 Pole 120 Volt 20KA L-N
MPN: 83020104
Alt. SKU: STPT2-40K150V-1P
Special Price
£34.69
£28.91
Regular Price
£46.25
Why Choose the STPT2-40K150V-1P Surge Protection Device?
This Type 2 surge protection device offers robust safeguarding for single-phase 120V electrical installations, providing reliable defence against transient overvoltages with a maximum discharge current (Imax) of 40kA (8/20μs). The 1-pole, L-N configuration ensures targeted protection for sensitive equipment in commercial and industrial environments.
Featuring a pluggable, compact 1-module design, the STPT2-40K150V-1P allows for quick installation and easy maintenance without system downtime. Depend on its proven performance to maintain system integrity and comply with international surge protection standards.
Product Code: 83020104
Key Benefits
- High surge current capacity with 40 kA maximum discharge current (Imax) for superior protection.
- Compact, pluggable 1-module design enables easy installation and replacement without system interruption.
- Clear visual indication system (Green OK / Replace) for simple status monitoring.
- Suitable for multiple system configurations including TNS, TNC, and TT (L-N only).
- Complies with IEC and UL standards ensuring reliable and safe operation.
Compatibility
The STPT2-40K150V-1P is compatible with single-phase 120V AC electrical systems and supports protection modes L-N, L-PE, and N-PE. It is designed to be mounted on standard DIN rails and is suitable for use in TNS, TNC, and TT system configurations (L-N only). The device can be used with back-up fuses up to 125 A [gG].
Applications
- Protection of sensitive electronic equipment in commercial buildings.
- Industrial electrical installations requiring robust surge protection.
- Single-phase power distribution boards in residential or light commercial environments.
- Systems requiring compliance with international surge protection standards.
Technical Specifications
- Item number: 83020104
- Catalogue No: STPT2-40K150V-1P
- Description: Surge Protection Device Type 2, 40kA Imax (8/20), 1Ph, 120V, L-N, 1 Pole, Pluggable, 1 Module
- EAN/UPC Code: 8435297850571
- RoHS Compliant: Yes
- IEC SPD Type: Class II
- UL SPD Type: Type 2 Component Assembly
- Format: Pluggable
- Nominal Operating Volt Rating (Un): 120
- AC or DC: AC
- Nominal Discharge Current (In) (8/20): 20 kA
- Max Discharge Current : Imax (8/20): 40 kA
- Protection Modes: L - N / L-PE / N-PE
- System Configuration: TNS, TNC, TT (only L-N)
- Short Circuit Withstand (ISCCR): 25 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace)
- Number of Poles: 1-pole
- Torque Rating: 3 Nm
- Max. Back-Up Fuse: 125 A [gG]
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Installation Mounting: DIN rail
- VPR L-N: 700 V
- Replacement Plug L1: 83020001
- Product Width: 18 mm
- Product Length: 70 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.13 kg
- Sell Pack Width: 24 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.108 kg
Frequently Asked Questions
What is the maximum surge current this device can handle?
The STPT2-40K150V-1P can handle a maximum discharge current (Imax) of 40 kA (8/20μs waveform).
Is this surge protection device suitable for three-phase systems?
No, this device is designed for single-phase 120V AC systems only.
How does the indication system work?
The device features a green indicator showing the SPD is operational. If the indicator is not green, the unit should be replaced.
Can this device be installed on a DIN rail?
Yes, the STPT2-40K150V-1P is designed for DIN rail mounting for easy installation.
What is the replacement plug part number?
The replacement plug for this device is part number 83020001.
Common Search Terms
Type 2 surge protector, 40kA surge protection device, single-phase SPD, pluggable surge protector, 120V surge protection, DIN rail SPD, electrical surge arrester, transient voltage suppressor, power line SPD, commercial surge protector
| Manufacturer Part Number | 83020104 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297850571 |
| Height | 70mm |
| Width | 18mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 1 pole |
| Voltage | 120V |
| Maximum Continuous Voltage | 150V |
| Nominal Discharge Current | 20Ka |
| System Type | L-N |
| Alternative Product SKU | STPT2-40K150V-1P |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
