Mersen Surge Protector Type 1+2 SPD 4 Pole 230/400 Volt 20KA TNS Remote Indication
MPN: 83120145
Alt. SKU: STPT12-12K275V-4PM
This product is discontinued. Please view this replacement item.
Why Choose the STPT12-12K275V-4PM Surge Protection Device?
Engineered for rigorous industrial and commercial applications, the Type 1+2 Surge Protection Device provides robust defence against transient overvoltages, with a high 12.5kA Iimp (10/350) rating per pole. Its 4-pole, pluggable design ensures straightforward installation and maintenance in 3Ph+N, 230/400V TNS systems.
The unit offers reliable protection for sensitive equipment, featuring four modules with remote indication for real-time system status. Compliant with latest standards, it is an ideal choice for comprehensive surge mitigation in critical power distribution networks.
Product Code: 83120145
Key Benefits
- High surge current capacity with 12.5kA lightning impulse current per pole for superior protection.
- Pluggable 4-pole design allows easy installation and maintenance in 3Ph+N systems.
- Remote indication system provides real-time status monitoring for proactive maintenance.
- Complies with IEC Class I+II standards ensuring reliable and certified surge protection.
- Durable PA66 CT1 housing material ensures long-lasting performance in industrial environments.
Compatibility
This surge protection device is compatible with 3-phase plus neutral (3Ph+N) TN-S electrical systems operating at 230/400V AC. It is designed for DIN rail mounting and suitable for integration into industrial and commercial power distribution boards requiring Class I+II surge protection.
Applications
- Industrial power distribution systems
- Commercial building electrical panels
- Critical infrastructure requiring surge mitigation
- Protection of sensitive electronic equipment in manufacturing plants
- Renewable energy installations with grid connection
Technical Specifications
- Item number: 83120145
- Catalogue No: STPT12-12K275V-4PM
- Description: Surge Protection Device Type 1+2, 12.5kA Iimp (10/350), 3Ph+N, 230/400V, 4+0 TNS, 4 Poles, Pluggable, 4 Modules, Remote indication
- EAN/UPC Code: 8435297849179
- RoHS Compliant: Yes
- IEC SPD Type: Class I+II
- Format: Pluggable
- Nominal Operating Volt Rating (Un): 230/400
- AC or DC: AC
- Max Discharge Current : Imax (8/20): 50 kA
- Protection Modes: L-PE / N-PE
- System Configuration: TNS
- Lightning Impulse Current (10/350) (LIMP): 12.5 kA
- Short Circuit Withstand (ISCCR): 25 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace) Microswitch
- Number of Poles: 4-Pole
- Torque Rating: 3 Nm
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Installation Mounting: DIN rail
- Replacement Plug N-PE: 83120002
- Replacement Plug L-N: 83120002
- Product Width: 72 mm
- Product Length: 76 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.69 kg
- Sell Pack Width: 78 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.68 kg
Frequently Asked Questions
What type of electrical systems is this SPD suitable for?
The STPT12-12K275V-4PM is designed for 3-phase plus neutral (3Ph+N) TN-S systems operating at 230/400V AC.
Does this device provide remote status indication?
Yes, it features a remote indication system with a green (OK) / not green (replace) microswitch for real-time monitoring.
Can this SPD be installed on a DIN rail?
Yes, the device is designed for DIN rail mounting for easy integration into electrical panels.
What is the maximum discharge current rating?
The maximum discharge current (Imax 8/20 µs) is 50 kA, providing robust surge protection.
Common Search Terms
Surge protection device, SPD 12.5kA, Type 1+2 surge protector, 4-pole SPD, pluggable surge protector, 230/400V surge protection, industrial surge protection, DIN rail SPD, remote indication SPD, TN-S system surge protection.
| Manufacturer Part Number | 83120145 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297849179 |
| Height | 76mm |
| Width | 72mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 4 Pole |
| Voltage | 230/400V |
| Maximum Continuous Voltage | 275V |
| Nominal Discharge Current | 20Ka |
| Remote Indication | Yes |
| System Type | TNS |
| Alternative Product SKU | STPT12-12K275V-4PM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
