Mersen Surge Protector Type 1+2 SPD 2 Pole 230 Volt 20KA TT
MPN: 83120114
Alt. SKU: STPT12-12K275V-2PG
This product is discontinued. Please view this replacement item.
Why Choose the STPT12-12K275V-2PG Surge Protection Device?
The STPT12-12K275V-2PG offers robust Type 1+2 surge protection, safely absorbing 12.5kA Iimp (10/350 µs) impulses for reliable defence of 1Ph+N, TT systems at 230V. Its precise two-pole, 1+1 configuration ensures comprehensive coverage for critical industrial or commercial electrical panels.
Engineered for convenience and longevity, this pluggable 2-module SPD facilitates rapid installation and maintenance, minimising downtime. Rigorously tested for high-performance, it delivers proven protection against transient overvoltages in demanding environments.
Technical Specifications
- Item number: 83120114
- Catalogue No: STPT12-12K275V-2PG
- Description: Surge Protection Device Type 1+2, 12.5kA Iimp (10/350), 1Ph+N, 230/-V, 1+1 TT, 2 Poles, Pluggable, 2 Modules
- EAN/UPC Code: 8435297851363
- RoHS Compliant: Yes
- IEC SPD Type: Class I+II
- Format: Pluggable
- Nominal Operating Volt Rating (Un): 230
- AC or DC: AC
- Max Discharge Current : Imax (8/20): 50 kA
- Protection Modes: L-N / N-PE
- System Configuration: TT, TNS
- Lightning Impulse Current (10/350) (LIMP): 12.5 kA
- Following Current (Ifi): 100 A
- Short Circuit Withstand (ISCCR): 25 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace)
- Number of Poles: 2-Pole
- Torque Rating: 3 Nm
- Max. Back-Up Fuse: 200 A [gG]
- Housing Material: PA66 CT1
- Installation Mounting: DIN rail
- Uc (L-N): 275 V
- Uc (N-PE): 255 V
- Up at In (N-PE): ≤1,5 kV
- Up at In (L-N): ≤1,3 kV
- Replacement Plug N-PE: 83120006
- Replacement Plug L-N: 83120002
- Product Width: 36 mm
- Product Length: 76 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.299 kg
- Sell Pack Width: 42 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.269 kg
Product Code: 83120114
Key Benefits
- High surge current capacity with 12.5kA lightning impulse current rating for superior protection.
- Pluggable 2-module design allows quick and easy installation and replacement.
- Two-pole 1+1 configuration ensures full protection of line and neutral conductors.
- Clear indication system with green (OK) / not green (replace) status for maintenance ease.
- Compatible with TT and TNS system configurations for versatile application.
- Durable PA66 CT1 housing ensures long-term reliability in industrial environments.
Compatibility
The STPT12-12K275V-2PG is compatible with single-phase plus neutral (1Ph+N) TT and TNS electrical systems operating at 230V AC. It fits standard DIN rail mounting systems and can be integrated seamlessly into existing industrial or commercial power distribution panels requiring Type 1+2 surge protection.
Applications
- Industrial power distribution boards
- Commercial electrical panels
- Protection of sensitive electronic equipment from transient overvoltages
- Buildings with TT and TNS earthing systems
- Renewable energy installations requiring surge protection
Frequently Asked Questions
What does Type 1+2 surge protection mean?
Type 1+2 surge protection devices provide protection against both direct lightning strikes (Type 1) and switching surges (Type 2), ensuring comprehensive defence for electrical installations.
Can this SPD be used in a TN-C system?
No, the STPT12-12K275V-2PG is designed for TT and TNS systems and is not suitable for TN-C configurations.
How do I know when to replace the SPD?
The device features an indication system that shows green when operational and changes colour when replacement is needed, allowing easy maintenance checks.
Is the device RoHS compliant?
Yes, this surge protection device complies with RoHS standards, ensuring it is free from hazardous substances.
Common Search Terms
surge protection device, SPD 12.5kA, Type 1+2 SPD, pluggable surge protector, 230V SPD, TT system surge protection, DIN rail SPD, industrial surge protector, electrical panel SPD
| Manufacturer Part Number | 83120114 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297851363 |
| Height | 76mm |
| Width | 36mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 2 Pole |
| Voltage | 230V |
| Maximum Continuous Voltage | 275V |
| Nominal Discharge Current | 20Ka |
| System Type | TT |
| Alternative Product SKU | STPT12-12K275V-2PG |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
