9006.10 Cembre EWO IP66 Black Rectangular Flat Seals
MPN: 9006.10
Alt. SKU: 3201412
Special Price
£1.85
£1.54
Regular Price
£2.46
9006.10 Cembre EWO IP66 Black Rectangular Flat Seals is available to buy in increments of 10
Why Choose the Cembre EWO 9006.10 IP66 Black Rectangular Flat Seals
The Cembre 9006.10 flat seal is a precision-engineered sealing accessory for the EWO split cable entry system. It provides a rectangular gasket tailored for the 10-module frame, ensuring an IP66 seal between the frame and the enclosure cut-out. This makes it an essential component for protecting against dust, water, and contaminants in machinery, automation systems, and industrial control cabinets.
Manufactured from durable elastomer in black (RAL 9005), the 9006.10 flat seal delivers reliable long-term performance. Designed to work with the 9020.10 frame and other 10-module layouts, it ensures a consistent and uniform compression seal for both new installations and retrofits.
Key Features
- Flat elastomer seal designed specifically for the EWO 10-module frame layout.
- Maintains IP66 ingress protection when installed with compatible frames and grommets.
- Made from chemical and weather-resistant thermoplastic elastomer (TPE).
- Colour: black (RAL 9005).
- Operating temperature range: -40 °C to +140 °C.
- Ensures reliable sealing performance across industrial environments.
- Reusable during maintenance if carefully removed and inspected.
Technical Specifications
- Manufacturer: Cembre
- Series: EWO split cable entry system – Flat Seals
- Model: 9006.10
- Function: Flat rectangular gasket for 10-module frame
- Material: Thermoplastic elastomer (TPE)
- Colour: Black (RAL 9005)
- Ingress Protection: IP66 with compatible EWO frame
- Operating Temperature (static): -40 °C to +140 °C
- Compatibility: EWO 10-module rectangular frame (9020.10)
Certifications
Conforms to certifications of the EWO system, including CE, UKCA, UL (cURus), and RINA. Delivers IP66 sealing performance when installed correctly. Material meets UL94 V-0 fire classification.
Comparison and Selection Notes
Use 9006.10 when sealing the 10-module rectangular EWO frame. For other layouts, consider 9006.16 (16 module), 9006.24 (24 module), or 9006.Q (square module) flat seals. For direct grommet sealing, use the dedicated EWO grommet seals.
Frequently Asked Questions
Applications
- Sealing the perimeter of 10-module rectangular EWO frames in control panels and enclosures.
- Ensuring IP66 performance in demanding industrial environments.
- Retrofits and upgrades where a secure flat seal is required.
Trusted By Installers
"The 9006.10 flat seal is quick to fit and keeps the 10-module frame reliably sealed." Panel Builder, UK
The 9006.10 is a flat sealing gasket designed for EWO 10-module rectangular frames, ensuring IP66 protection between the frame and the panel cut-out.
Yes. When installed with the correct 9020.10 frame and compatible grommets, the 9006.10 delivers IP66 ingress protection.
It is designed for use with the 9020.10 rectangular frame layout of the EWO system.
Yes, if carefully removed and found free of deformation or damage, but for critical sealing tasks replacement is recommended.
| Manufacturer Part Number | 9006.10 |
|---|---|
| Alternative Product SKU | 3201412 |
| Manufacturer | Cembre |
| Degree of protection (IP) | IP66 |
| Colour | Black |
| Material | NBR |
| Packed Quantity | 10 |
| Depth | 2.5mm |
