132F0007 Danfoss VLT Micro Drive FC-51 2.2KW/3.0 HP 200-240VAC IP20, No Display - to be phased out

Why Choose the Danfoss 132F0007 VLT Micro Drive FC 51?

The Danfoss 132F0007 is a compact and powerful AC variable frequency drive (VFD) from the Danfoss VLT® Micro Drive FC 51 series, designed for efficient speed control of three-phase AC motors in industrial, commercial and machine automation applications. Built for reliable performance in a space-saving format, this micro drive helps improve energy efficiency, process control and mechanical reliability.

As part of the proven Danfoss VLT Micro Drive FC 51 range, the 132F0007 offers dependable motor control with a compact M3 chassis, integrated EMC filtering and coated PCB construction. Its practical design makes it suitable for panel builders, OEM machine manufacturers and maintenance engineers requiring a robust frequency converter for everyday industrial motor speed control.

With a rated output power of 2.2 kW / 3.0 HP and a single-phase 200–240 V AC supply, the Danfoss 132F0007 is ideal for three-phase motor applications where compact installation and accurate speed control are required. The drive includes a brake chopper, has an IP20 chassis protection rating and is designed for cabinet or control panel mounting.

Key Advantages

• Compact variable frequency drive for AC motor speed control.
• 2.2 kW / 3.0 HP output power rating for industrial and OEM applications.
• Single-phase 200–240 V AC input suitable for low-voltage installations.
• 9.6 A output current for compatible three-phase motor systems.
• Integrated RFI Class A1/B (C1) filter to support EMC requirements.
• Built-in brake chopper for dynamic braking applications.

Key Features

• Danfoss VLT® Micro Drive FC 51 series.
• 2.2 kW rated output power.
• 9.6 A rated output current.
• Single-phase 200–240 V AC input supply.
• Three-phase motor output.
• IP20 / chassis protection rating.
• Built-in RFI Class A1/B (C1) filter.
• Brake chopper included.
• No local control panel supplied.
• Coated PCB for improved durability in demanding environments.
• M3 frame size for control panel installation.

Technical Specifications

• Manufacturer: Danfoss
• Series: VLT® Micro Drive FC 51
• Model: 132F0007
• Type code: FC-051P2K2S2E20H3BXCXXXSXXX
• Product type: AC variable frequency drive / frequency converter
• Rated output power: 2.2 kW / 3.0 HP
• Rated output current: 9.6 A
• Input voltage: 200–240 V AC
• Input phases: 1-phase
• Output phases: 3-phase
• Input frequency: 50 / 60 Hz
• Protection rating: IP20 / chassis
• RFI filter: Class A1/B (C1)
• Brake chopper: Yes
• Local control panel: No
• PCB: Coated
• Mains option: No mains option
• Mounting type: Panel / cabinet mounting
• Frame size: M3
• Dimensions (H × W × D): approx. 239 × 90 × 194 mm
• Weight: approx. 3.0 kg

Efficient Motor Control for Demanding Applications

Variable frequency drives such as the Danfoss 132F0007 control motor speed by adjusting the voltage and frequency supplied to the motor. This allows machinery to operate at the required speed rather than continuously running at full output, helping reduce energy consumption, improve process stability and extend equipment service life.

The VLT Micro Drive FC 51 series is designed for simple installation and reliable day-to-day operation in compact motor control systems. With integrated EMC filtering, coated circuit boards and a panel-friendly chassis, the 132F0007 is a practical choice for machine builders, panel builders and maintenance engineers.

Typical Applications

• Pumps and fan systems.
• Conveyors and material handling equipment.
• Packaging and production machinery.
• HVAC and ventilation equipment.
• OEM machine building and automation systems.
• General industrial three-phase motor speed control.

Trusted by Automation and Maintenance Engineers

Danfoss VLT Micro Drive FC 51 frequency converters are widely used by machine builders, panel builders and maintenance engineers for compact, efficient and reliable motor speed control.
