Wago 750-615 Power Supply, 120 Vac Fuse

Why Choose the WAGO 750-615 Power Supply Module?

The WAGO 750-615 is a reliable 120 V AC field power supply module designed for the WAGO I/O System 750 and 753. It supplies the required field-side voltage to connected automation modules, ensuring stable operation of decentralised PLC and fieldbus control systems used in modern industrial automation environments.

Part of the WAGO automation product range, this module distributes 120 V AC supply voltage to downstream modules through integrated power jumper contacts. This design allows engineers to maintain consistent field voltage across modular I/O assemblies while simplifying wiring inside industrial control cabinets.

The module includes a replaceable 5 × 20 mm fuse holder for circuit protection and features LED indicators that display the status of the supply voltage and fuse condition. The module can provide up to 6.3 A of supply current to connected I/O modules, making it suitable for distributed automation nodes requiring AC field power. :contentReference

Key Advantages

• Provides reliable 120 V AC field supply for WAGO I/O modules.
• Supports up to 6.3 A current capacity for distributed I/O assemblies.
• Includes a replaceable fuse holder for circuit protection.
• Status LEDs indicate power supply and fuse condition.
• Compact DIN rail module for high-density control cabinets.
• Compatible with WAGO I/O System 750 and 753 automation platforms.

Key Features

• Field power supply module for WAGO I/O systems.
• Supply voltage: 120 V AC.
• Maximum current: 6.3 A.
• Integrated fuse holder with replaceable 5 × 20 mm fuse.
• LED indicators for supply voltage and fuse status.
• CAGE CLAMP spring terminals for secure wiring.
• DIN-35 rail mounting for industrial control cabinets.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750 / 753
• Model: 750-615
• Module type: Field power supply module
• Supply voltage: 120 V AC
• Maximum current: 6.3 A
• Fuse type: 5 × 20 mm (T 6.3 A, not included)
• Power jumper contact capacity: 6.3 A
• Connection technology: CAGE CLAMP spring terminals
• Wire cross section: approx. 0.08 to 2.5 mm² (AWG 28–14)
• Mounting type: DIN-35 rail
• Width: approx. 12 mm
• Height: approx. 100 mm
• Depth: approx. 69.8 mm
• Protection rating: IP20
• Operating temperature: approx. 0 °C to +55 °C

Industrial Automation Power Distribution

Distributed automation systems rely on stable field-side power supplies to ensure sensors, actuators and output modules operate reliably across machines and production lines. Field supply modules allow engineers to distribute AC voltage across modular I/O assemblies without installing separate terminal blocks or external power distribution components.

The WAGO 750-615 supplies field voltage to downstream modules and integrates protection and status monitoring within the automation node. If additional current capacity is required, extra supply modules can be installed within the assembly to segment power zones and maintain safe system operation. :contentReference

Typical Applications

• Distributed PLC and fieldbus I/O systems.
• Industrial machine control panels.
• Factory automation and manufacturing equipment.
• Control cabinets requiring AC field supply for I/O modules.
• Process automation and industrial monitoring systems.

Trusted by Automation Engineers

WAGO I/O System 750 modules are widely trusted by automation engineers and machine builders for creating reliable, scalable distributed control systems.
