Wago 750-563/040-000 2-channel analog output module 0/4-20 mA 16 bits or 6 to 18VDC configurable, XTR - Extreme version Dark Gray

Why Choose the WAGO 750-563/040-000 Relay Output Module?

The WAGO 750-563/040-000 is a robust 8-channel relay output module designed for the WAGO I/O System 750 and 753 distributed automation platform. It enables PLCs and fieldbus controllers to switch AC or DC loads using mechanical relay contacts, creating a reliable interface between low voltage control signals and higher voltage field circuits.

Each output channel features a potential free relay contact, allowing the module to control devices such as contactors, solenoid valves, pumps, motors, alarms and signalling equipment. This makes the module suitable for industrial automation, machine control and building management systems where dependable switching of electrical loads is required.

The module’s compact DIN rail housing integrates easily into control cabinets and distributed I/O stations. WAGO’s proven CAGE CLAMP® spring pressure connection technology ensures fast wiring, secure connections and vibration resistant operation for long term reliability in demanding industrial environments.

Key Advantages

• 8 relay output channels for switching multiple electrical loads.
• Potential free relay contacts suitable for AC and DC circuits.
• Provides galvanic isolation between PLC control electronics and field equipment.
• Compact DIN rail module for efficient control cabinet layouts.
• CAGE CLAMP® spring pressure terminals for quick and reliable wiring.
• Fully compatible with the WAGO I/O System 750 and 753.

Key Features

• 8-channel relay output module.
• Potential free relay contacts.
• Mechanical relay switching for AC and DC loads.
• Electrical isolation between system and field circuits.
• DIN rail mounting for industrial control cabinets.
• CAGE CLAMP® spring connection technology.
• Part of the WAGO distributed I/O architecture.
• Designed for industrial automation and building control systems.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750 / 753
• Model: 750-563/040-000
• Module type: Relay output module
• Number of outputs: 8 relay outputs
• Contact type: Potential free relay contacts
• Maximum switching voltage: approx. 250 V AC / 30 V DC
• Maximum switching current: approx. 2 A per channel
• Switching type: Mechanical relay
• System supply voltage: 5 V DC via internal system bus
• Connection technology: CAGE CLAMP® spring connection
• Mounting type: 35 mm DIN rail
• Dimensions: approx. 100 × 24 × 67.8 mm
• Operating temperature: -20 °C to +60 °C
• Protection rating: IP20
• Isolation: galvanic isolation between system and field circuits
• Approvals: CE, UL and international industrial approvals

Reliable Distributed Automation with WAGO I/O

The WAGO I/O System 750/753 provides a modular distributed automation platform widely used across manufacturing plants, machine building and building management systems. Digital, analogue and communication modules can be combined to create scalable industrial control architectures.

Relay output modules such as the 750-563/040-000 provide reliable switching of higher voltage loads while electrically isolating PLC electronics from field equipment. This ensures safe, stable operation across industrial automation installations.

Typical Applications

• Industrial automation control systems.
• PLC controlled relay switching.
• Machine control and manufacturing equipment.
• Switching AC loads and higher voltage circuits.
• Alarm and signalling equipment.
• Building automation and facility management systems.

Trusted by Automation Engineers

WAGO relay output modules are trusted worldwide by machine builders and automation engineers for reliable switching performance, electrical isolation and seamless integration within distributed industrial control systems.
