Wago 750-534 8-channel digital output; 12 VDC; 1 A

Why Choose the WAGO 750-534 Digital Output Module?

The WAGO 750-534 is a high-performance 4-channel digital output module designed for use within the WAGO I/O System 750 and 753 distributed automation platform. It enables PLCs and fieldbus controllers to switch and control field devices such as relays, contactors, solenoids and signalling devices within industrial control systems.

Each output channel provides reliable 24 V DC switching with up to 2 A output current, allowing the module to control higher-power loads while maintaining fast switching and dependable operation. The module’s compact 12 mm width supports high-density I/O configurations in control cabinets while maintaining efficient heat dissipation.

Built with WAGO’s proven CAGE CLAMP® spring pressure connection technology, the module enables quick installation and vibration-resistant wiring. This connection system ensures long-term reliability in demanding industrial environments and reduces installation time for machine builders and system integrators.

Key Advantages

• 4 digital output channels for industrial automation control.
• 24 V DC switching outputs compatible with standard PLC systems.
• Up to 2 A output current per channel for higher-power loads.
• Compact 12 mm housing enabling high I/O density.
• CAGE CLAMP® spring connection technology for secure wiring.
• Fully compatible with the WAGO I/O System 750 and 753.

Key Features

• 4-channel digital output module.
• 24 V DC output voltage.
• Maximum 2 A output current per channel.
• High-side switching outputs.
• Short-circuit and overload protection.
• Compact 12 mm DIN rail module.
• CAGE CLAMP® spring terminals.
• Designed for integration into the WAGO distributed I/O architecture.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750 / 753
• Model: 750-534
• Module type: Digital output module
• Number of outputs: 4 digital outputs
• Output voltage: 24 V DC
• Output current per channel: up to 2 A
• Switching type: High-side switching
• Switching frequency: up to approx. 1 kHz
• System supply voltage: 5 V DC via internal system bus
• Connection technology: CAGE CLAMP® spring connection
• Mounting type: 35 mm DIN rail
• Module width: 12 mm
• Dimensions: approx. 100 × 12 × 67.8 mm
• Operating temperature: -20 °C to +60 °C
• Protection rating: IP20
• Isolation voltage: approx. 500 V system/field
• Approvals: CE, UL and international industrial certifications

Reliable Distributed Automation with WAGO I/O

The WAGO I/O System 750/753 is a flexible distributed automation platform widely used in machine control, process automation and industrial production systems. The modular design allows digital, analogue and communication modules to be combined to create scalable control architectures.

Digital output modules such as the 750-534 transmit switching signals from PLC controllers to field devices. Their robust design and high current capability make them well suited for driving industrial loads across a wide range of automation applications.

Typical Applications

• Industrial automation control panels.
• PLC-based machine control systems.
• Distributed I/O installations.
• Driving relays, solenoids and contactors.
• Production lines and factory automation.
• Material handling, robotics and packaging equipment.

Trusted by Automation Engineers

WAGO distributed I/O modules are widely trusted by machine builders and automation engineers for their reliability, modular design and compact installation within modern industrial control systems.
