Wago 750-523 1Do, 230 Vac 16A Pot-Free Relay1No

Why Choose the WAGO 750-523 Digital Output Module?

The WAGO 750-523 is a compact 8-channel digital output module designed for the WAGO I/O System 750. It enables PLCs and industrial controllers to control field devices such as relays, solenoid valves, signal lamps and actuators within distributed automation systems.

Each output channel provides a 24 V DC high-side switching output with a maximum switching current of 0.5 A per channel. The module is designed for reliable control of industrial loads while maintaining electrical isolation between the controller electronics and the field wiring.

The module integrates seamlessly with WAGO fieldbus couplers and programmable controllers, forming part of the flexible WAGO 750 distributed I/O platform. Its slim DIN rail housing and CAGE CLAMP® spring terminal technology allow fast installation and secure wiring inside control cabinets.

Key Advantages

• 8 digital output channels for compact control of multiple devices.
• 24 V DC high-side switching outputs.
• 0.5 A switching current per channel.
• Reliable switching of industrial loads such as relays and valves.
• Compatible with WAGO 750 Series distributed I/O systems.
• Quick installation using CAGE CLAMP® spring terminals.

Key Features

• 8 digital output channels.
• Output voltage: 24 V DC.
• Output type: high-side switching.
• Maximum output current: 0.5 A per channel.
• Short-circuit protection integrated.
• Status LEDs indicate output state.
• Compatible with WAGO fieldbus couplers and programmable controllers.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750
• Model: 750-523
• Module type: Digital output module
• Number of outputs: 8 digital channels
• Output voltage: 24 V DC
• Output type: High-side switching
• Maximum output current: 0.5 A per channel
• Short-circuit protection: Yes
• Isolation: Field/system isolation
• System supply voltage: 5 V DC via internal I/O bus
• Field supply voltage: 24 V DC
• Connection technology: CAGE CLAMP® spring terminals
• Mounting: 35 mm DIN rail
• Module width: approx. 12 mm
• Operating temperature: 0 °C to +55 °C
• Ingress protection: IP20

Industrial Digital Output Control

Digital output modules provide the interface between PLC control logic and field devices in industrial automation systems. They convert controller signals into switching outputs that operate relays, valves, lamps and other actuators used throughout automated equipment.

The WAGO 750-523 enables compact multi-channel switching in distributed automation systems. When integrated into the WAGO 750 distributed I/O platform, it allows engineers to build scalable machine automation systems with efficient control of multiple field devices.

Typical Applications

• PLC control of relays and contactors.
• Industrial signalling and indicator devices.
• Solenoid valve and actuator control.
• Machine automation systems.
• Distributed PLC and remote I/O architectures.
