Why Choose the WAGO 750-506/000-800 Digital Output Module?

The WAGO 750-506/000-800 is a robust 4-channel digital output module designed for the WAGO I/O System 750. It enables PLCs and industrial controllers to control field devices such as relays, contactors, solenoid valves and signalling lamps within distributed automation systems.

Each output channel provides 24 V DC high-side switching with a maximum switching current of 2 A per channel. This allows the module to drive higher-power actuators and loads commonly used in machine automation and industrial process control applications.

The module integrates seamlessly with WAGO fieldbus couplers and programmable controllers, forming part of the flexible WAGO 750 modular I/O architecture. Its compact DIN rail housing and CAGE CLAMP® spring terminal technology ensure fast installation and secure wiring in industrial control cabinets.

Key Advantages

• 4 digital output channels for industrial automation control.
• 24 V DC switching outputs rated up to 2 A per channel.
• High-side switching outputs suitable for industrial loads.
• Integrated short-circuit protection for improved reliability.
• Seamless integration with WAGO 750 Series distributed I/O systems.
• Quick installation using CAGE CLAMP® spring terminals.

Key Features

• 4 digital output channels.
• Output type: 24 V DC high-side switching.
• Maximum output current: 2 A per channel.
• Integrated short-circuit protection.
• Status LEDs indicate output status.
• Compact DIN rail module for control cabinet installations.
• Compatible with WAGO fieldbus couplers and controllers.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750
• Model: 750-506/000-800
• Module type: Digital output module
• Number of outputs: 4 digital channels
• Output voltage: 24 V DC
• Maximum output current: 2 A per channel
• Output characteristic: High-side switching
• Isolation: 500 V system/field isolation
• System supply voltage: 5 V DC via internal I/O bus
• Field supply voltage: 24 V DC (−25 % to +30 %)
• Connection technology: CAGE CLAMP® spring terminals
• Mounting: 35 mm DIN rail
• Module width: approx. 12 mm
• Operating temperature: 0 °C to +55 °C
• Ingress protection: IP20

Industrial Digital Output Control

Digital output modules form the interface between PLC logic and field devices. They convert controller signals into switching outputs that operate relays, lamps, contactors and other actuators used throughout industrial automation systems.

The WAGO 750-506/000-800 provides reliable switching capability for higher-power loads while maintaining seamless integration within the WAGO 750 Series distributed I/O platform. This enables engineers to design scalable machine automation systems, distributed control networks and remote I/O architectures.

Typical Applications

• PLC control of relays and contactors.
• Solenoid valve and actuator switching.
• Machine automation and industrial control systems.
• Status indicators and signalling devices.
• Distributed PLC and remote I/O architectures.

Trusted by Automation Engineers

WAGO 750 Series I/O modules are trusted worldwide by automation engineers and machine builders for building reliable distributed control systems across manufacturing, infrastructure and industrial automation environments.
