Wago 750-489 4AI RTD/TC/Strain Exi Blue

Why Choose the WAGO 750-489 Analogue Output Module?

The WAGO 750-489 is a precision 2-channel analogue output module designed for the WAGO I/O System 750. It converts digital control values from PLCs or industrial controllers into stable ±10 V analogue voltage signals, allowing accurate bidirectional control of drives, actuators and industrial process equipment.

Each output channel generates a high-accuracy voltage signal commonly used in advanced automation systems where positive and negative control ranges are required. This enables control systems to drive equipment such as servo drives, positioning systems and precision motion control devices.

Designed for distributed automation architectures, the module integrates seamlessly with WAGO fieldbus couplers and programmable controllers. The compact DIN-rail housing and CAGE CLAMP® spring terminal connections allow fast installation and dependable long-term electrical performance in industrial control cabinets.

Key Advantages

• Reliable 2-channel analogue voltage output for advanced automation systems.
• Supports ±10 V control signals for bidirectional control applications.
• High-precision digital-to-analogue conversion for accurate motion and process control.
• Seamless integration with WAGO 750 Series distributed I/O systems.
• Compact modular design for scalable automation architectures.
• Fast installation using CAGE CLAMP® spring terminal technology.

Key Features

• 2 analogue output channels.
• Output signal type: voltage.
• Output range: ±10 V.
• Resolution: 12-bit digital-to-analogue conversion.
• High signal stability for precision control applications.
• DIN-rail mounting for WAGO modular I/O nodes.
• Compatible with WAGO fieldbus couplers and controllers.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750
• Model: 750-489
• Module type: Analogue output module
• Number of outputs: 2 analogue channels
• Signal type: Voltage
• Output range: ±10 V
• Resolution: 12 bit
• Typical conversion time: approx. 5 ms
• Output load: typically ≥ 2 kΩ
• Supply voltage: 24 V DC via power jumper contacts
• System supply voltage: 5 V DC via internal bus
• Connection technology: WAGO CAGE CLAMP® spring terminals
• Mounting: 35 mm DIN rail
• Ingress protection: IP20
• Operating temperature: 0 °C to +55 °C

Precision Analogue Voltage Control in Automation

Bidirectional analogue signals such as ±10 V are commonly used in industrial automation for applications requiring precise control in both directions. These signals allow PLCs and controllers to manage servo drives, motion control systems and positioning equipment with high accuracy.

The WAGO 750-489 module converts digital control values from the automation controller into stable analogue voltage outputs. When combined with other modules in the WAGO 750 Series distributed I/O platform, it enables flexible and scalable automation architectures across manufacturing and advanced machinery applications.

Typical Applications

• Servo drive and motion control systems.
• Industrial automation and machine control.
• Positioning and actuator control applications.
• Precision process control equipment.
• Distributed PLC and remote I/O architectures.

Trusted by Automation Engineers

WAGO 750 Series I/O modules are trusted by automation engineers and system integrators worldwide for building reliable distributed control systems across industrial manufacturing and advanced machinery applications.
