Wago 750-486 4-channel analog input; 0/4 … 20 mA; Single-ended; 12 bits; Diagnostics; Intrinsically safe

Why Choose the WAGO 750-486 Analogue Output Module?

The WAGO 750-486 is a precise 2-channel analogue output module designed for the WAGO I/O System 750. It converts digital control values from PLCs or industrial controllers into stable 0–10 V voltage signals, enabling accurate control of drives, actuators and process equipment within modern automation systems.

Each channel provides an independent voltage output capable of driving analogue control inputs commonly used in industrial equipment. This allows automation systems to regulate devices such as variable frequency drives, proportional valves, dampers and analogue instrumentation with high precision.

Designed for distributed control architectures, the module integrates directly with WAGO fieldbus couplers and programmable controllers. The compact DIN-rail housing and CAGE CLAMP® spring terminal connections ensure fast installation and reliable long-term electrical performance inside industrial control cabinets.

Key Advantages

• Reliable 2-channel analogue voltage output for automation systems.
• Supports standard 0–10 V control signals.
• Accurate digital-to-analogue conversion for stable process control.
• Seamless integration with WAGO 750 Series distributed I/O systems.
• Compact modular design for scalable automation installations.
• Fast installation using CAGE CLAMP® spring terminal technology.

Key Features

• 2 analogue output channels.
• Output signal type: voltage.
• Output range: 0–10 V.
• Resolution: 12-bit digital-to-analogue conversion.
• High signal stability for precise control applications.
• DIN-rail mounting for WAGO modular I/O systems.
• Compatible with WAGO fieldbus couplers and controllers.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750
• Model: 750-486
• Module type: Analogue output module
• Number of outputs: 2 analogue channels
• Signal type: Voltage
• Output range: 0…10 V
• Resolution: 12 bit
• Typical conversion time: approx. 5 ms
• Output load: typically ≥ 2 kΩ
• Supply voltage: 24 V DC via power jumper contacts
• System supply voltage: 5 V DC via internal bus
• Connection technology: WAGO CAGE CLAMP® spring terminals
• Mounting: 35 mm DIN rail
• Ingress protection: IP20
• Operating temperature: 0 °C to +55 °C

Industrial Analogue Voltage Control

Voltage control signals such as 0–10 V are widely used in industrial automation for regulating equipment including drives, dampers and proportional valves. These signals allow PLCs and control systems to deliver continuous analogue control outputs rather than simple on/off switching.

The WAGO 750-486 module converts digital values from the automation controller into accurate analogue voltage outputs. When combined with other modules in the WAGO 750 Series distributed I/O platform, it enables flexible and scalable control architectures across manufacturing and industrial process environments.

Typical Applications

• Industrial automation and machine control systems.
• Variable frequency drive speed control.
• Control of proportional valves and actuators.
• HVAC and building automation control systems.
• Distributed PLC and remote I/O architectures.

Trusted by Automation Engineers

WAGO 750 Series I/O modules are trusted worldwide by machine builders and automation engineers to build reliable distributed control systems across manufacturing, infrastructure and industrial facilities.
