Wago 750-486/040-000 4-channel analog output module 0/4-20 mA configurable Ex i with diagnostics Cat. Ia, XTR - Extreme version Dark Blue

Why Choose the WAGO 750-486/040-000 Analogue Output Module?

The WAGO 750-486/040-000 is a reliable 2-channel analogue output module from the WAGO I/O System 750 XTR range. It converts digital process values from PLCs and industrial controllers into stable 0…10 V analogue voltage signals, enabling accurate control of drives, actuators and analogue process equipment in demanding automation environments.

Each channel delivers an independent voltage output commonly used in industrial automation for controlling equipment such as variable frequency drives, proportional valves, dampers and analogue instrumentation. The module ensures stable and accurate signal conversion for precise regulation of process equipment.

As part of the WAGO XTR (Extreme) series, the module is engineered for harsh operating conditions including extended temperature ranges and increased resistance to vibration and electromagnetic interference. It integrates seamlessly with WAGO fieldbus couplers and programmable controllers to create scalable distributed I/O systems.

Key Advantages

• Reliable 2-channel analogue voltage output for industrial automation.
• Supports standard 0–10 V control signals.
• XTR rugged design for harsh industrial environments.
• Accurate digital-to-analogue conversion for stable control signals.
• Seamless integration with WAGO 750 Series distributed I/O systems.
• Quick installation using CAGE CLAMP® spring terminals.

Key Features

• 2 analogue output channels.
• Output signal type: voltage.
• Output range: 0…10 V.
• Resolution: 12-bit digital-to-analogue conversion.
• Integrated diagnostics and signal monitoring.
• XTR industrial design for extreme operating environments.
• Compatible with WAGO fieldbus couplers and controllers.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750 XTR
• Model: 750-486/040-000
• Module type: Analogue output module
• Number of outputs: 2 analogue channels
• Signal type: Voltage
• Output range: 0…10 V
• Resolution: 12 bit
• Typical conversion time: approx. 5 ms
• Output load: typically ≥ 2 kΩ
• Field supply voltage: 24 V DC via power jumper contacts
• System supply voltage: 5 V DC via internal I/O bus
• Connection technology: WAGO CAGE CLAMP® spring terminals
• Mounting: 35 mm DIN rail
• Operating temperature: −40 °C to +70 °C (XTR extended range)
• Ingress protection: IP20

Industrial Voltage Control in Automation Systems

Analogue voltage signals such as 0–10 V are widely used in automation systems for controlling equipment requiring proportional regulation rather than simple switching. PLCs generate these signals to adjust the speed of drives, position of actuators or output of control devices.

The WAGO 750-486/040-000 module converts digital controller values into precise analogue voltage outputs. When combined with other modules in the WAGO 750 Series distributed I/O platform, it enables flexible automation architectures across manufacturing, infrastructure and process industries.

Typical Applications

• Industrial automation and machine control.
• Variable frequency drive speed control.
• Control of proportional valves and actuators.
• HVAC and building automation systems.
• Distributed PLC and remote I/O architectures.

Trusted by Automation Engineers

WAGO 750 Series I/O modules are widely trusted by automation engineers and system integrators to build reliable distributed control systems across industrial manufacturing, energy and infrastructure applications.
