Wago 750-414 4Di, 5 Vdc 0.2ms

Why Choose the WAGO 750-414 4-Channel Digital Input Module?

The WAGO 750-414 is a robust 4-channel digital input module designed for use within the WAGO I/O System 750. It allows controllers to detect 24 V DC digital signals from sensors, switches and other field devices, enabling reliable monitoring of machine states and automation processes.

The module converts incoming field signals into digital data that can be read by a connected WAGO fieldbus coupler or programmable controller. Each channel includes LED status indication and signal filtering, helping ensure stable signal acquisition and simplified diagnostics in industrial control systems.

Designed for industrial automation environments, the module uses WAGO CAGE CLAMP® spring pressure connection technology, providing secure vibration-resistant wiring and rapid installation. Its compact DIN rail housing allows efficient integration into high-density control cabinets and modular distributed I/O systems.

Key Advantages

• Reliable 4-channel digital input module for automation systems.
• Supports standard 24 V DC digital control signals.
• Compatible with the modular WAGO 750 Series I/O platform.
• Integrated input filtering for stable signal detection.
• CAGE CLAMP® spring terminals ensure secure and maintenance-free wiring.
• Compact DIN rail design ideal for space-efficient control cabinets.

Key Features

• 4 digital input channels.
• 24 V DC input signal voltage.
• Designed for monitoring digital sensors and switches.
• LED indicators for each channel status.
• Compatible with common industrial sensor wiring configurations.
• DIN rail mounted modular I/O design.
• CAGE CLAMP® spring connection technology.
• Compatible with WAGO 750 Series fieldbus couplers and controllers.

Technical Specifications

• Manufacturer: WAGO
• Series: WAGO I/O System 750
• Model: 750-414
• Module type: Digital input module
• Number of inputs: 4 channels
• Input voltage: 24 V DC
• Signal type: Digital DC
• Input current per channel: approx. 3 mA
• Input filter: approx. 0.5–3 ms
• Connection technology: CAGE CLAMP® spring terminals
• Mounting: 35 mm DIN rail
• Protection rating: IP20
• Operating temperature: approx. 0 °C to +55 °C
• Typical use: Digital signal monitoring from field devices

Industrial Digital Signal Monitoring

Digital input modules provide the essential interface between field devices and industrial control systems. They convert electrical signals from sensors, switches and machine contacts into digital data that PLCs and automation controllers use to control equipment and processes.

The modular architecture of the WAGO 750 Series enables scalable distributed I/O systems. Additional modules can be added easily as automation systems expand, allowing engineers to build flexible and efficient control networks across production facilities.

Typical Applications

• Monitoring proximity sensors and limit switches.
• PLC signal acquisition in industrial machinery.
• Machine status monitoring on production lines.
• Distributed factory automation networks.
• Building automation and facility monitoring.

Trusted by Automation Engineers

WAGO 750 Series I/O modules are widely used by machine builders and automation engineers to build reliable distributed control systems across manufacturing and industrial automation environments.
