Wago 750-1605 Potential Distribution, 1624V

Why Choose the WAGO 750-1605 8-Channel Digital Input Module?

The WAGO 750-1605 is a compact 8-channel digital input module designed for integration with the modular WAGO I/O System 750. It enables reliable acquisition of 24 V DC digital signals from sensors, switches and other field devices used in industrial automation systems.

With eight independent input channels within a single module, the 750-1605 helps machine builders and system integrators expand control systems efficiently while reducing cabinet space and wiring complexity. Each input includes LED status indication, providing quick visual diagnostics during installation and operation.

The module connects directly to compatible WAGO fieldbus couplers and controllers, enabling dependable signal communication between field-level devices and PLC-based automation systems across distributed control architectures.

Key Advantages

• Efficient 8-channel digital input acquisition.
• Supports standard 24 V DC industrial sensor signals.
• Designed for the modular WAGO I/O System 750.
• Compact DIN rail module for high-density control cabinets.
• LED indicators for quick signal diagnostics.
• Reliable signal communication between field devices and PLC systems.

Key Features

• 8 digital input channels.
• 24 V DC digital signal inputs.
• Compatible with WAGO I/O System 750.
• LED status indication for each channel.
• Modular distributed I/O design.
• DIN rail mounting for industrial control panels.
• Reliable acquisition of sensor and switch signals.

Technical Specifications

• Manufacturer: WAGO
• Series: I/O System 750
• Model: 750-1605
• Module type: Digital input module
• Number of inputs: 8
• Input signal type: 24 V DC digital
• Input current: approx. 3 mA typ.
• Input filter time: approx. 3 ms
• Status indication: LED per input channel
• Connection technology: CAGE CLAMP® spring pressure terminals
• Mounting: DIN rail (EN 60715)
• System compatibility: WAGO I/O System 750 fieldbus couplers and controllers
• Operating temperature: approx. −20 °C to +60 °C
• Application: Digital signal acquisition from sensors and switches

Industrial Automation Signal Acquisition

Digital input modules act as the interface between field devices and automation controllers. The WAGO 750-1605 allows industrial sensors, push buttons and switching devices to transmit status signals to PLC systems within distributed automation architectures.

By using modular distributed I/O systems, automation engineers can place signal modules closer to field equipment. This reduces wiring complexity and improves diagnostics, reliability and maintenance across industrial automation installations.

Typical Applications

• Industrial machine automation and PLC control systems.
• Digital signal acquisition from sensors and switches.
• Distributed I/O installations in manufacturing plants.
• Production line monitoring and machine signalling.
• Building automation and control cabinets.

Trusted by Automation Engineers

WAGO I/O modules are widely trusted by automation engineers and machine builders to create reliable distributed control systems across modern industrial environments.
