Wago 750-1516 8-channel digital output module 24 VDC low-side switching 2-conductor connection
MPN: 750-1516
Alt. SKU: 7501516
Special Price
£81.40
£67.83
Regular Price
£95.76
Why Choose the WAGO 750-1516 16-Channel Digital Input Module?
The WAGO 750-1516 is a high-density 16-channel digital input module developed for the modular WAGO I/O System 750. It enables reliable acquisition of 24 V DC digital signals from industrial sensors, switches and control devices used in distributed automation systems.
Designed for efficient control cabinet layouts, the module provides sixteen independent input channels within a compact housing. This allows machine builders and automation engineers to monitor multiple signals while minimising panel space and simplifying field wiring.
Each channel features a clear LED status indicator for fast diagnostics and commissioning. The module integrates directly with WAGO fieldbus couplers and programmable controllers, allowing seamless communication between field devices and PLC-based automation systems.
Key Advantages
- High-density 16-channel digital input acquisition.
- Designed for the modular WAGO I/O System 750.
- Supports standard 24 V DC industrial input signals.
- Compact DIN rail module for efficient panel layouts.
- LED indicators for quick signal diagnostics.
- Reliable signal transmission between field devices and PLC systems.
Key Features
- 16 digital input channels.
- 24 V DC digital input signals.
- Compatible with WAGO I/O System 750.
- LED status indication for each channel.
- Modular distributed I/O architecture.
- DIN rail mounting for control cabinets.
- Reliable signal acquisition from industrial sensors and switches.
Technical Specifications
- Manufacturer: WAGO
- Series: I/O System 750
- Model: 750-1516
- Module type: Digital input module
- Number of inputs: 16
- Input signal type: 24 V DC digital
- Input current: approx. 3 mA typ.
- Input filter time: approx. 3 ms
- Status indication: LED per input channel
- Connection technology: CAGE CLAMP® spring pressure terminals
- Mounting: DIN rail (EN 60715)
- System compatibility: WAGO I/O System 750 fieldbus couplers and controllers
- Operating temperature: approx. −20 °C to +60 °C
- Application: Digital signal acquisition from sensors and switches
Industrial Automation Signal Acquisition
Digital input modules provide the interface between field-level devices and PLC control systems. The WAGO 750-1516 allows sensors, push buttons and switching devices to transmit status signals to automation controllers within distributed control architectures.
Distributed I/O systems allow automation engineers to position signal acquisition modules closer to field devices, reducing wiring complexity while improving maintenance, diagnostics and system reliability across industrial facilities.
Typical Applications
- Industrial automation and machine control systems.
- PLC digital input signal acquisition.
- Distributed I/O installations across manufacturing equipment.
- Production line monitoring and automation equipment.
- Building automation and facility management systems.
Frequently Asked Questions
What does the WAGO 750-1516 module do?
The module collects digital signals from sensors, switches and field devices and transmits them to an automation controller or PLC.
How many input channels does the module provide?
The 750-1516 provides sixteen digital input channels, allowing multiple signals to be monitored within one module.
What input voltage signals are supported?
The module is designed for 24 V DC digital input signals, which are standard in industrial automation systems.
Which automation platforms use this module?
The module is part of the WAGO I/O System 750 and works with compatible WAGO fieldbus couplers and programmable controllers.
Where is the module typically installed?
It is commonly installed in PLC control cabinets, distributed automation systems and machine control panels.
Trusted by Automation Engineers
WAGO I/O modules are widely used by machine builders and system integrators to create reliable distributed automation systems across modern industrial environments.
| Manufacturer Part Number | 750-1516 |
|---|---|
| Height | 104mm |
| Width | 20mm |
| Depth | 74mm |
| Manufacturer | Wago |
| Packed Quantity | 1 |
| HS Code | 85371098 |
| Barcode | 4050821085652 |
| Country of Manufacture | Germany |
| Alternative Product SKU | 7501516 |
