Wago 750-1505 16Do, 24 Vdc 0.5A Lss

Why Choose the WAGO 750-1505 8-Channel Digital Input Module?

The WAGO 750-1505 is a reliable 8-channel digital input module designed for use within the modular WAGO I/O System 750. It enables efficient acquisition of 24 V DC digital signals from sensors, switches and control devices within industrial automation systems.

By allowing eight independent input channels within a compact module, the 750-1505 helps machine builders and system integrators expand automation systems while maintaining efficient cabinet space utilisation. Each channel includes clear LED indication for fast diagnostics and system monitoring.

As part of WAGO’s distributed I/O architecture, this module connects directly to compatible fieldbus couplers and programmable controllers, allowing reliable signal transmission between field devices and PLC control systems across modern industrial networks.

Key Advantages

• High-density 8-channel digital input acquisition for automation systems.
• Supports standard 24 V DC industrial sensor signals.
• Compatible with the modular WAGO I/O System 750.
• Space-saving DIN rail design for control cabinets.
• Integrated LED indicators for fast signal diagnostics.
• Reliable signal transfer between field devices and PLC controllers.

Key Features

• 8 digital input channels.
• 24 V DC input signals.
• Designed for WAGO I/O System 750.
• LED status indication for each channel.
• Modular distributed I/O architecture.
• DIN rail mounting for industrial control panels.
• Compatible with WAGO fieldbus couplers and controllers.

Technical Specifications

• Manufacturer: WAGO
• Series: I/O System 750
• Model: 750-1505
• Module type: Digital input module
• Number of inputs: 8
• Input signal type: 24 V DC digital
• Input current: approx. 3 mA typ.
• Input filter time: approx. 3 ms
• Status indication: LED per input channel
• Connection technology: CAGE CLAMP® spring pressure terminals
• Mounting: DIN rail (EN 60715)
• System compatibility: WAGO I/O System 750 fieldbus couplers and controllers
• Operating temperature: approx. −20 °C to +60 °C
• Application: Digital signal acquisition from field devices

Industrial Automation Signal Acquisition

Digital input modules provide the essential interface between field devices and automation controllers. The WAGO 750-1505 enables sensors, switches and signalling devices to transmit status information to PLC systems within distributed automation architectures.

Using modular I/O systems allows machine builders to reduce control cabinet wiring and place signal processing closer to field equipment. This improves installation efficiency, diagnostics and overall system reliability in modern industrial environments.

Typical Applications

• Industrial automation and machine control systems.
• PLC input signal acquisition.
• Distributed I/O installations.
• Production line monitoring and machine safety systems.
• Building automation and control cabinets.

Trusted by Automation Engineers

WAGO I/O modules are widely trusted by automation engineers and system integrators for building scalable, reliable distributed control systems across industrial environments.
