Wago 750-1504 16Do, 24 Vdc 0.5A

Why Choose the WAGO 750-1504 4-Channel Digital Input Module?

The WAGO 750-1504 is a compact 4-channel digital input module designed for use with the WAGO I/O System 750. It enables reliable acquisition of 24 V DC digital signals from sensors, switches and field devices in industrial automation systems.

Installed on the modular WAGO fieldbus node, the module provides efficient signal transmission between field devices and the control system. Its four independent input channels allow machine builders and system integrators to monitor multiple signals within a single compact module.

Engineered for demanding automation environments, the 750-1504 integrates seamlessly into distributed I/O architectures used in manufacturing systems, building automation, machine control and process applications.

Key Advantages

• Reliable 4-channel digital input acquisition for automation systems.
• Designed for the modular WAGO I/O System 750 architecture.
• Supports 24 V DC industrial sensor signals.
• Compact DIN rail module for high-density control panels.
• Quick installation and integration with WAGO fieldbus couplers and controllers.
• Reliable signal transmission between field devices and PLC systems.

Key Features

• 4 digital input channels.
• 24 V DC signal input.
• Compatible with WAGO I/O System 750.
• LED status indication for each input channel.
• Modular design for distributed I/O systems.
• DIN rail mounted automation module.
• Supports industrial sensor and switch inputs.

Technical Specifications

• Manufacturer: WAGO
• Series: I/O System 750
• Model: 750-1504
• Module type: Digital input module
• Number of inputs: 4
• Input signal type: 24 V DC digital
• Input current: approx. 3 mA typ.
• Input filter time: approx. 3 ms
• Signal status indication: LED per channel
• Mounting: DIN rail (EN 60715)
• System compatibility: WAGO I/O System 750 fieldbus couplers and controllers
• Connection technology: CAGE CLAMP® spring pressure terminals
• Operating temperature: approx. −20 °C to +60 °C
• Application: Digital signal acquisition from sensors and switches
