Wago 750-1500 16Do, 24 Vdc 0.5A Ribbon Cable

Why Choose the WAGO 750-1500 Digital Output Module?

The WAGO 750-1500 is a compact 2-channel digital output module designed for the modular WAGO I/O SYSTEM 750. It enables industrial automation systems to control actuators, relays and other field devices by transmitting digital switching signals from the controller to connected outputs.

Part of the trusted WAGO automation portfolio, the module communicates with the fieldbus controller and delivers output signals to field devices within distributed automation systems. Its modular architecture allows engineers to create scalable distributed I/O installations by combining multiple digital and analogue modules according to system requirements.

The module mounts directly onto the WAGO I/O SYSTEM 750 backplane and installs on a 35 mm DIN rail. Its compact housing makes it ideal for machine automation, manufacturing equipment and building automation control panels where reliable switching of digital outputs is required.

Key Advantages

• Controls up to 2 digital output channels for actuators and switching devices.
• Compatible with the modular WAGO I/O SYSTEM 750.
• Compact module design for space-efficient control cabinets.
• Reliable switching for industrial automation applications.
• Simple integration with WAGO fieldbus controllers.
• Scalable architecture for distributed I/O installations.

Key Features

• 2-channel digital output module.
• Compatible with WAGO I/O SYSTEM 750.
• Designed for distributed automation systems.
• DIN rail mountable modular housing.
• Suitable for controlling relays, actuators and signalling devices.
• Integrated status LEDs for channel diagnostics.
• Expandable system configuration with additional I/O modules.

Technical Specifications

• Manufacturer: WAGO
• Series: I/O SYSTEM 750
• Model: 750-1500
• Product type: Digital output module
• Number of outputs: 2
• Output type: Digital
• System compatibility: WAGO I/O SYSTEM 750
• Mounting: DIN rail 35 mm (EN 60715)
• Status indication: Channel LEDs
• Application: Switching and control of field devices in industrial automation

Distributed I/O for Industrial Automation

Distributed I/O modules allow automation controllers to communicate with sensors and actuators located throughout a machine or facility. By installing decentralised input and output modules close to field devices, engineers can significantly reduce wiring complexity and improve system flexibility.

The WAGO I/O SYSTEM 750 platform is widely used by machine builders and system integrators because of its modular expansion capability, compact installation footprint and reliable communication with industrial fieldbus networks.

Typical Applications

• Industrial automation systems.
• Machine control and manufacturing equipment.
• Actuator and relay control.
• Distributed control system installations.
• Building automation and infrastructure control.

Trusted by Automation Engineers

WAGO distributed I/O modules are widely used by automation engineers and system integrators worldwide for reliable machine control and scalable industrial automation architectures.
