Wago 750-1416/040-000 8-channel digital input; 24 VDC; 0.2 ms; 2-conductor connection; Extreme

Why Choose the WAGO 750-1416/040-000 Digital Input Module?

The WAGO 750-1416/040-000 is a high-density 16-channel digital input module designed for the modular WAGO I/O SYSTEM 750. It allows automation systems to monitor multiple digital signals from sensors, switches and other field devices, enabling efficient signal acquisition within distributed industrial automation systems.

Part of the reliable WAGO automation portfolio, this module communicates with a compatible fieldbus controller and transfers input signals from connected field devices to the control system. Its modular architecture allows engineers to expand automation installations easily by adding additional digital or analogue I/O modules according to the needs of the application.

The module installs directly onto the WAGO I/O SYSTEM 750 backplane and mounts on a 35 mm DIN rail. Its compact design and high channel density allow efficient signal monitoring in control cabinets used for machine automation, production systems and building automation installations.

Key Advantages

• Monitors up to 16 digital input signals from sensors and switches.
• Compatible with the modular WAGO I/O SYSTEM 750.
• High channel density for compact control cabinet installations.
• Reliable signal acquisition for industrial automation systems.
• Simple integration with WAGO fieldbus controllers.
• Scalable architecture for flexible distributed I/O systems.

Key Features

• 16-channel digital input module.
• Compatible with WAGO I/O SYSTEM 750.
• Designed for distributed automation architectures.
• DIN rail mountable modular housing.
• Supports connection of sensors, switches and digital field signals.
• Integrated status LEDs for channel diagnostics.
• Expandable system configuration with additional I/O modules.

Technical Specifications

• Manufacturer: WAGO
• Series: I/O SYSTEM 750
• Model: 750-1416/040-000
• Product type: Digital input module
• Number of inputs: 16
• Input type: Digital
• System compatibility: WAGO I/O SYSTEM 750
• Mounting: DIN rail 35 mm (EN 60715)
• Status indication: Channel LEDs
• Application: Monitoring digital field signals in industrial automation systems

Distributed I/O for Industrial Automation

Distributed I/O modules allow sensors and field devices to connect directly to decentralised input and output modules instead of routing wiring back to a central PLC cabinet. This architecture reduces wiring complexity and improves flexibility in modern industrial automation systems.

The WAGO I/O SYSTEM 750 platform is widely used by machine builders and system integrators due to its modular expansion capability, compact installation footprint and reliable industrial communication performance.

Typical Applications

• Industrial automation systems.
• Machine building and production equipment.
• Sensor monitoring in manufacturing processes.
• Distributed control and automation installations.
• Building automation and infrastructure monitoring.

Trusted by Automation Engineers

WAGO distributed I/O modules are trusted worldwide by automation engineers and system integrators for reliable signal acquisition and scalable industrial automation architectures.
