Wago 2206-8031 Distribution terminal block
MPN: 2206-8031
Alt. SKU: 22068031
Wago 2206-8031 Distribution terminal block is available to buy in increments of 12
Why Choose the WAGO 2206-8031 TOPJOB S Jumper Bar?
The WAGO 2206-8031 is a high-quality insulated jumper bar designed for fast and reliable potential distribution across WAGO TOPJOB S 2206 Series DIN rail terminal blocks. This accessory allows multiple terminals to be electrically bridged together, simplifying power distribution and signal routing within industrial control panels.
By inserting the jumper into the integrated jumper slot of compatible terminal blocks, engineers can quickly create common potential groups without additional wiring. This reduces installation time, improves panel organisation and ensures consistent electrical connections across terminal rows.
The jumper bar features a robust insulated housing and precision-engineered contacts, ensuring reliable electrical conductivity and safe operation within demanding industrial environments. Designed specifically for WAGO’s modular terminal block system, it integrates seamlessly into modern control cabinet layouts.
Key Advantages
- Fast potential distribution across multiple terminal blocks.
- Reduces panel wiring complexity and installation time.
- Designed specifically for WAGO TOPJOB S 2206 Series terminals.
- Reliable electrical contact with insulated safety design.
- Improves control cabinet organisation.
- Quick installation without additional wiring.
Key Features
- Insulated jumper bar for terminal block bridging.
- Compatible with WAGO TOPJOB S 2206 Series.
- Designed for common potential distribution.
- Precision contacts for reliable electrical conductivity.
- Snap-in installation into terminal jumper slots.
- Compact accessory for organised panel wiring.
Technical Specifications
- Manufacturer: WAGO
- Series: TOPJOB S 2206 Series
- Model: 2206-8031
- Type: Insulated jumper bar
- Function: Potential distribution between terminal blocks
- Compatible terminals: WAGO 2206 Series
- Installation: Integrated jumper slot
- Material: Insulated housing with conductive bridge contacts
- Application: Power and signal bridging in control panels
Efficient Potential Distribution in Control Panels
Industrial automation systems often require multiple terminals to share the same electrical potential. Jumper bars simplify this process by allowing terminals to be connected together quickly without additional wiring, improving installation efficiency and reducing potential wiring errors.
The WAGO TOPJOB S terminal block system offers a complete ecosystem of modular accessories designed for modern industrial automation and electrical installations. These systems are frequently used alongside equipment such as industrial signalling and automation devices to create scalable control and distribution panels.
Typical Applications
- Power distribution in control cabinets.
- Signal potential bridging in terminal assemblies.
- Industrial automation and PLC wiring.
- Machine building and panel manufacturing.
- Electrical distribution panels.
Frequently Asked Questions
What is the WAGO 2206-8031 used for?
The 2206-8031 is a jumper bar used to electrically bridge multiple WAGO 2206 Series terminal blocks, allowing them to share a common electrical potential.
Which terminals is this jumper compatible with?
This jumper is designed specifically for use with WAGO TOPJOB S 2206 Series DIN rail terminal blocks.
How is the jumper installed?
The jumper is inserted directly into the integrated jumper slot of compatible terminal blocks, creating an electrical bridge between them.
Why are jumper bars used in control panels?
Jumper bars simplify wiring by allowing multiple terminals to share a common electrical potential without additional wiring, reducing installation time and improving panel organisation.
Are jumper bars insulated?
Yes. WAGO jumper bars feature insulated housings that protect against accidental contact while maintaining reliable electrical conductivity.
Trusted by Electrical Engineers
WAGO TOPJOB S accessories are trusted worldwide by panel builders and automation engineers for creating efficient, organised and reliable electrical control systems.
| Manufacturer Part Number | 2206-8031 |
|---|---|
| Height | 132mm |
| Width | 80mm |
| Depth | 50mm |
| Manufacturer | Wago |
| Packed Quantity | 12 |
| HS Code | 85369010 |
| Barcode | 4066966185805 |
| Terminal Type | Distribution |
| Terminal Size | 6mm |
| Colour | Grey |
| Type of electric connection | Push-in clamp connection |
| Country of Manufacture | Germany |
| Alternative Product SKU | 22068031 |
