VXR-RS485 2nd RS485 / Modbus RTU port

Why Choose the IMO VXR-RS485 Communication Card?

The IMO VXR-RS485 is a dedicated RS485 communication option card designed for the IMO Jaguar VXR inverter drive series. Engineered to provide reliable industrial serial communications, this option module enables seamless integration of VXR variable frequency drives into automation systems and industrial control networks using RS485 serial communication protocols.

Designed for professional industrial environments, the VXR-RS485 option card provides dependable communication between inverter drives, PLCs, HMIs and SCADA systems. The module connects through an RJ45 communication interface, allowing straightforward installation and integration into industrial automation infrastructures.

As part of the IMO Jaguar VXR ecosystem, the VXR-RS485 communication card supports enhanced drive monitoring, parameter configuration and remote control functionality. Its compact design allows easy installation directly into compatible IMO Jaguar VXR inverter drives without requiring significant panel modifications.

Key Advantages

• Dedicated RS485 communication interface for IMO Jaguar VXR drives.
• Supports industrial automation and remote drive monitoring.
• RJ45 communication connection for straightforward integration.
• Enables communication with PLCs, HMIs and SCADA systems.
• Compact plug-in option card design.
• Designed specifically for IMO Jaguar VXR inverter applications.
• Improves system integration and centralised control capability.

Key Features

• IMO Jaguar VXR communication option card.
• RS485 serial communication interface.
• RJ45 communication port connection.
• Compatible with IMO Jaguar VXR inverter drives.
• Supports industrial automation integration.
• Compact plug-in module construction.
• Industrial-grade communication reliability.
• Suitable for remote monitoring and control applications.

Technical Specifications

• Manufacturer: IMO Precision Controls
• Series: Jaguar VXR
• Model: VXR-RS485
• Product type: RS485 communication option card
• Communication protocol: RS485 serial communication
• Connection type: RJ45
• Compatible products: IMO Jaguar VXR inverter drives
• Mounting method: Plug-in option card
• Application: Industrial drive communication and networking
• Use case: PLC, HMI and SCADA integration
• Industrial compatibility: Automation and process control systems
• Communication function: Remote monitoring and parameter configuration

Reliable Industrial Drive Communication

Industrial communication modules such as the IMO VXR-RS485 allow variable speed drives to communicate with supervisory control systems, enabling remote configuration, diagnostics, monitoring and automation control. RS485 communication is widely used in industrial environments because of its reliability, noise immunity and suitability for long-distance communication networks.

The VXR-RS485 option card extends the functionality of compatible IMO Jaguar VXR drives by allowing integration into modern automation systems where centralised monitoring and coordinated motor control are required.

Typical Applications

• Industrial automation systems.
• PLC and HMI communication networks.
• SCADA integration for inverter drives.
• Remote drive monitoring and diagnostics.
• Process control and machine automation.
• Conveyor, pump and fan drive systems.
• Factory automation and industrial networking.

Trusted by Industrial Automation Engineers

IMO Jaguar VXR communication accessories are widely used in industrial automation systems to provide dependable drive networking, remote monitoring and efficient machine integration.
