132F0059 Danfoss VLT Micro Drive FC-51 15KW/20 HP 380-480VAC IP20, No Display - to be phased out

Why Choose the Danfoss 132F0059 VLT Micro Drive FC-51?

The Danfoss 132F0059 is a compact and powerful AC variable frequency drive (VFD) designed for reliable speed control of three-phase motors in industrial machinery, HVAC equipment and automation systems. As part of the Danfoss VLT Micro Drive FC-51 series, it combines dependable motor performance with a space-saving design for efficient installation in control panels and machine cabinets.

This drive is engineered for applications requiring simple commissioning, robust operation and flexible motor control. The VLT Micro Drive FC-51 range is known for compact construction, intuitive parameter setup and reliable protection functions, helping panel builders, machine manufacturers and maintenance engineers achieve efficient motor control with minimal installation effort.

With a rated output power of 15 kW / 20 HP, a 31 A output current and a three-phase 380–480 V AC supply, the Danfoss 132F0059 is suitable for conveyors, pumps, fans, compressors and process machinery. Its IP20 chassis format, RFI Class A1/B filtering and dynamic braking capability make it a practical choice for demanding industrial drive applications.

Key Advantages

• Compact variable frequency drive for three-phase motor control.
• 15 kW / 20 HP motor power rating for demanding industrial applications.
• Three-phase 380–480 V AC input compatible with standard industrial supplies.
• 31 A maximum output current for dependable motor performance.
• Integrated dynamic braking capability for controlled deceleration.
• Built-in RFI Class A1/B filter for improved electromagnetic compatibility.
• Compact IP20 chassis design for panel and cabinet installation.

Key Features

• Danfoss VLT Micro Drive FC-51 series.
• 15 kW / 20 HP rated output power.
• 31 A maximum output current.
• Three-phase 380–480 V AC input supply.
• RFI Class A1/B filtering.
• Dynamic braking support.
• RS485 communication with FC Protocol and Modbus RTU support.
• VVC+ and U/f motor control modes.
• Panel-mounted IP20 / chassis enclosure format.
• Suitable for industrial machinery, HVAC and automation systems.

Technical Specifications

• Manufacturer: Danfoss
• Series: VLT Micro Drive FC-51
• Model: FC-051P15KT4E20H3BXCXXXSXXX
• Part number: 132F0059
• Product type: AC variable frequency drive
• Rated output power: 15 kW / 20 HP
• Maximum output current: 31 A
• Input voltage: 380–480 V AC
• Input phases: 3-phase
• Output phases: 3-phase
• Supply frequency: 50 / 60 Hz
• Output frequency: 0–200 Hz VVC+ / 0–400 Hz U/f
• Protection rating: IP20 / chassis
• Frame size: M4
• RFI filter: Class A1/B (C1)
• Communication: RS485, FC Protocol, Modbus RTU
• Dimensions (H × W × D): approx. 292 × 125 × 241 mm
• Weight: approx. 6 kg

Reliable Motor Control for Industrial and HVAC Systems

Variable frequency drives such as the Danfoss VLT Micro Drive FC-51 regulate motor speed by adjusting output voltage and frequency. This improves process control, reduces mechanical stress and helps lower energy use in applications where motors do not need to operate continuously at full speed.

The 132F0059 is designed for dependable motor control in compact installations. With integrated EMC filtering, communication options and dynamic braking capability, it is suitable for both new installations and replacement drive applications across machinery, building services and industrial automation systems.

Typical Applications

• Industrial conveyors and material handling systems.
• Pumps, fans and HVAC equipment.
• Compressors and ventilation systems.
• Mixers, agitators and processing machinery.
• Packaging and production equipment.
• Control panels and OEM machinery installations.

Trusted by Industrial and HVAC Engineers

Danfoss VLT Micro Drive FC-51 inverters are trusted by panel builders, machine manufacturers and maintenance engineers for compact motor control, reliable performance and efficient operation in industrial and building service applications.
