VACON 20 VACON0020-3L-0003-4+EMC2+QPES - 0.75Kw/2.4AMP 3 PHASE IN/OUT IP21

Why Choose the Vacon 0020-3L-0003-4+EMC2+QPES Inverter Drive?

The Vacon 0020-3L-0003-4+EMC2+QPES is a compact and versatile AC variable frequency drive (VFD) from the highly regarded Vacon 20 series, designed for efficient speed control of three-phase motors in OEM machinery, industrial automation, pumps, fans and material handling applications.

The Vacon 20 range combines compact dimensions with advanced functionality, offering built-in PLC capability, flexible I/O configuration and fieldbus connectivity. The +EMC2 version includes an integrated EMC Class 2 filter for improved electromagnetic compatibility, while the +QPES option provides a PE plate kit for simplified installation and cable management.

With a rated motor power of 0.75 kW, a rated output current of 2.4 A and operation from a three-phase 380-480 V AC supply, the Vacon 0020-3L-0003-4+EMC2+QPES delivers reliable motor control in a compact IP20 / UL Open Type enclosure suitable for panel mounting.

Key Advantages

• Compact AC variable frequency drive for OEM and industrial applications.
• 0.75 kW motor power rating for three-phase motor control.
• 2.4 A rated output current.
• Three-phase 380-480 V AC input suitable for industrial power systems.
• IP20 / UL Open Type enclosure for panel installation.
• EMC Class 2 filter integrated as standard.
• PE plate kit supplied with the +QPES configuration.
• Built-in PLC functionality and RS-485 communications.

Key Features

• Vacon 20 compact inverter drive series.
• 0.75 kW rated motor power.
• 2.4 A rated current.
• Three-phase 380-480 V AC input supply.
• IP20 / UL Open Type enclosure.
• EMC Class 2 filtering.
• Built-in PLC functionality based on IEC 61131.
• RS-485 communications interface.
• Fieldbus support capability.
• MI01 frame size.
• No brake chopper fitted.
• Fast installation and commissioning.

Technical Specifications

• Manufacturer: Danfoss / Vacon
• Series: Vacon 20
• Model: VACON0020-3L-0003-4+EMC2+QPES
• Product type: AC variable frequency drive
• Rated output power: 0.75 kW
• Rated output current: 2.4 A
• Input voltage: 380-480 V AC
• Input phases: 3-phase
• Output phases: 3-phase
• Frequency: 50 / 60 Hz
• Protection rating: IP20 / UL Open Type
• EMC level: EMC Class 2
• Frame size: MI01
• Dimensions (W × H × D): 66 × 160 × 98 mm
• Net weight: Approximately 0.55 kg
• Mounting type: Panel / drive module mounting

Flexible Motor Control for OEM Applications

The Vacon 20 series is designed specifically for machine builders and panel manufacturers requiring reliable motor speed control in a compact package. Built-in PLC functionality can reduce the need for external control hardware, helping simplify system design and reduce installation costs.

Integrated communications, flexible I/O and straightforward parameter configuration make the Vacon 0020-3L-0003-4+EMC2+QPES suitable for a wide range of industrial automation tasks where space-saving installation and dependable performance are important.

Typical Applications

• OEM machinery.
• Packaging equipment.
• Conveyors and material handling systems.
• Pumps and fans.
• Industrial automation systems.
• Process control equipment.
• Production machinery.
• Control panel integration projects.

Trusted by Machine Builders and Automation Engineers

Vacon 20 inverter drives are widely used by OEMs, control panel builders and industrial automation professionals who require compact dimensions, flexible control functionality and dependable motor performance.
