VACON 100 FLOW VACON0100-3L-0061-5-FLOW 30Kw/61Amp 3 PHASE IN/OUT IP21
MPN: 135N0960
Alt. SKU: 70-AB3L00615W06B220BM2H-00049063
Special Price
£3,009.10
£2,507.58
Regular Price
£5,233.20
Why Choose the Vacon 0100-3L-0061-5-FLOW Inverter Drive?
The Vacon 0100-3L-0061-5-FLOW is a high-performance Vacon 100 FLOW AC variable frequency drive designed for pumps, fans and flow-control applications in HVAC, building automation, water treatment and industrial process systems.
With a rated motor power of 30 kW, a rated output current of 61 A and operation from a three-phase 380-500 V AC supply, this drive provides efficient and reliable motor speed control for demanding flow-based applications.
Key Advantages
- Dedicated FLOW inverter drive for pump and fan applications.
- 30 kW motor power rating.
- 61 A rated output current.
- Three-phase 380-500 V AC input.
- IP21 / NEMA 1 enclosure.
- Graphical keypad for simple commissioning.
- C2 EMC level for commercial and industrial environments.
- Advanced PID and multipump control functionality.
Key Features
- Vacon 100 FLOW series.
- 30 kW rated motor power.
- 61 A rated output current.
- 380-500 V AC three-phase input.
- Three-phase motor output.
- IP21 / NEMA 1 enclosure.
- Graphical multilingual keypad.
- C2 EMC filter.
- Integrated PID controller.
- Multipump and cascade control functions.
- Built-in Ethernet communications.
- Modbus, N2 and BACnet support.
- Integrated Safe Torque Off functionality.
- MR07 frame size.
Technical Specifications
- Manufacturer: Danfoss / Vacon
- Series: Vacon 100 FLOW
- Model: VACON0100-3L-0061-5-FLOW
- Product type: AC variable frequency drive
- Rated output power: 30 kW
- Rated output current: 61 A
- Input voltage: 380-500 V AC
- Input phases: 3-phase
- Output phases: 3-phase
- Output frequency: 0-320 Hz
- Protection rating: IP21 / NEMA 1
- EMC level: C2 commercial and industrial environment
- Keypad: Graphical keypad
- Frame size: MR07
- Application type: Pumps, fans, HVAC and flow control
Typical Applications
- HVAC fan systems.
- Booster pump stations.
- Water treatment facilities.
- Wastewater processing plants.
- Building management systems.
- Cooling tower fans.
- Industrial pumping systems.
- Process flow control applications.
Frequently Asked Questions
What is the Vacon 0100-3L-0061-5-FLOW used for?
This drive is designed for controlling pumps, fans and flow-control applications in HVAC, water treatment and industrial process systems.
What motor size can this drive control?
The drive is rated for motors up to approximately 30 kW.
What supply voltage is required?
The drive operates from a three-phase 380-500 V AC supply.
Does the drive include pump-specific functions?
Yes. The Vacon 100 FLOW range includes dedicated pump and fan functions including PID control, multipump operation and application-specific flow-control menus.
What enclosure rating does this drive have?
The drive is supplied with an IP21 / NEMA 1 enclosure, suitable for installation in plant rooms and electrical enclosures.
Trusted by HVAC and Water Industry Professionals
Vacon 100 FLOW drives are used by HVAC engineers, system integrators, water treatment specialists and industrial automation professionals for dependable pump and fan control.
| Manufacturer Part Number | 135N0960 |
|---|---|
| Barcode | 5710108171292 |
| Filter | Filter Included |
| Input Phases | Three Phase |
| Degree of protection (IP) | IP21 |
| KW Rating | 30kW |
| Output Phases | Three phase |
| VSD Range | Danfoss Vacon 100 Flow |
| Manufacturer | Vacon |
| Alternative Product SKU | 70-AB3L00615W06B220BM2H-00049063 |
