131B3161 Danfoss VLT Automation Drive FC 300 5.5 KW / 7.5 HP, 380 - 500 VAC, IP20
MPN: 131B3161
Alt. SKU: FC-302P5K5T5E20H1XGXXXXSXXXXA0BKCXXXXDX
Special Price
£1,810.80
£1,509.00
Regular Price
£2,414.40
Why Choose the 131B3161?
The Danfoss 131B3161 (model code FC-302P5K5T5E20H1XGXXXXSXXXXA0BKCXXXXDX) is a Variable speed drive (frequency converter) intended for panel installation where accurate motor control, repeatable commissioning, and reliable like-for-like replacement are required.
Configured with Power: (P5K5) 5.5 KW / 7.5 HP, Current: 11, Supply: 380 - 500 VAC, Phase: Three phase, Enclosure: (E20) IP20 / Chassis, EMC/RFI: (H1) RFI Class A1/B (C1) to support correct selection and like-for-like replacements.
Key Benefits
- Variable speed drive (frequency converter) for correct application matching
- Configured with Power: (P5K5) 5.5 KW / 7.5 HP, Current: 11, Supply: 380 - 500 VAC, Phase: Three phase, Enclosure: (E20) IP20 / Chassis, EMC/RFI: (H1) RFI Class A1/B (C1).
- Suitable for panel installations where reliable commissioning is required.
- SKU and model code shown for procurement and like for like replacements.
Technical Specifications
- Series: 302
- Power Rating: (P5K5) 5.5 KW / 7.5 HP
- Mains Voltage: 380 - 500 VAC
- Phase: Three phase
- Enclosure: (E20) IP20 / Chassis
- RFI Filter: (H1) RFI Class A1/B (C1)
- Height [mm]: 268,0
- Width w/ no C options [mm]: 130,0
- Depth [mm]: 205,0
- Net weight: 6.71 Kilogram
- EAN: 5702427224148
- A Option: PROFIBUS DP MCA 101
- Adaptation A: Standard Cable Entries
- Adaptation B: No adaptation
- B Option: MCB-101 General purp. I/O
- Brake - Safe Stop: No brake chopper
- C Option Software: No software option
- C0 Option MCO: No C0 option
- C1 Option: No C1 option
- Coating PCB: Not coated PCB
- Continuous Current (HO) [A]: 11
- D Option: No D option
- Depth with Option A/B [mm]: 220,0
- Frame Size: A3
- Gross weight: 7.716 Kilogram
- Intermittent Current (HO) [A]: 17.6
- LCP: Graphical Loc. Cont. Panel
- Mains Option: No Mains Option
- Modelcode01: FC-302P5K5T5E20H1XGX
- Modelcode02: XXXSXXXXA0BKCXXXXDX
- Power 160% (HO) [KW]: 5.5
- Power Loss HO [W]: 187
- Product Group: VLT® AutomationDrive FC-
- Software Language Pack: Standard Language Pack
- Software Release: Latest release std. SW.
- Typecode Part 1: FC-302P5K5T5E20H1XGX
- Typecode Part 2: XXXSXXXXA0BKCXXXXDX
- Width w/ two C options [mm]: 190,0
Frequently Asked Questions
What supply does Danfoss 131B3161 require?
It is specified for 380 - 500 VAC. Match this to your incoming mains.
What is the rated power for 131B3161?
The listed power rating is (P5K5) 5.5 KW / 7.5 HP. Confirm sizing against your motor and duty cycle.
What enclosure class is it?
It is listed as (E20) IP20 / Chassis and is intended for installation in a suitable cabinet/enclosure as required.
Does it include an EMC/RFI filter?
The configuration is shown as (H1) RFI Class A1/B (C1). Choose a filtered variant or external filtering if your site requires it.
Where is 131B3161 typically installed?
In control panels or cabinets. Follow Danfoss installation guidance for clearances, earthing, and protective devices.
What does IP20 mean for 131B3161?
IP20 indicates protection against finger contact and solid objects over 12.5 mm. Install in a suitable enclosure to meet your site requirements.
| Manufacturer Part Number | 131B3161 |
|---|---|
| Barcode | 5702427224148 |
| Height | 268mm |
| Width | 130mm |
| Depth | 205mm |
| Filter | Filter Included |
| Input Phases | Three Phase |
| Degree of protection (IP) | IP20 |
| KW Rating | 5.5kW |
| Output Phases | Three phase |
| VSD Range | Danfoss VLT Automation Drive FC 300 |
| Manufacturer | Danfoss |
| Alternative Product SKU | FC-302P5K5T5E20H1XGXXXXSXXXXA0BKCXXXXDX |
Write Your Own Review
|
<> |
Simple installation and Start Up Danfoss drives come with pluggable spring loaded I/O terminals, each have a dual connector configuration which faclilitates a simple installation. When the customer requirees a high IP rated drive pre-threaded cable gland openeins can be ordered allowing for an easy and realible installation in harsh enviroments The automation drives graphical control panel option ensures the drive is simple to set up, commission and operate saving on installation and operating costs. |
There are various enclosures options available up to IP 66 (depending on the model). Integrated DC chokes and RFI filters in all models protect installations by minimizing harmonic distortion and electromagnetic interference.
The VLT Automation Drive has an integrated motion controller (IMC) functionality that can be used with applications where the drive is required to perform high-precision positioning and synchronisation operations. The Integrated Motion Controller (IMC) functionality is now configurable in the drive’s software. No additional modules or hardware are necessary.
To ensure the highest quality and reliability all Danfoss drives are fully tested at the factory. They require little maintenance and can ensure there is a fast return on investment.
Supply voltages and power range
3 x 200-240 V...0.25-37 kW
3 x 380-500 V...0.37 kW – 1.1 MW
3 x 525-600 V...0.75-75 kW
3 x 525-690 V...1.1 kW – 1.4 MW
Low harmonic drive
3 x 380-480 V...132-710 kW
12-pulse drive
3 x 380-690 V...250-1200 kW
Features and benefits
- There’s less need for cooling or oversizing as the ambient temperature is 50°C without derating
- The need for PLC capacity is reduced thanks to Smart Logic Control
- Low lifetime costs are ensured as the drive is highly resistant to wear and tear
- The lifetime of electronics is prolonged due to back-channel cooling for frames D, E and F
- Commissioning and upgrades are easy due to plug-in technology
- High-precision position and synchronization thanks to availability of Integrated Motion Controller throughout the entire product range
- Features such as intelligent heat management, Safe stop and Safe Torque Off ensure safe and energy-efficient operation of the drive
Applications
Conveyors, positioning and synchronizing, cranes, mixers, centrifuges and palletizing and packaging machinery.
PC tools
VLT® Motion Control Tool MCT 10
VLT® Motion Control Tool MCT 31
SISTEMA
Danfoss HCS (Harmonic Calculation Software)
Danfoss Servo Sizer
VLT® Energy Box
