US15-B10-B1 Unitronics PLC + HMI Unistream 15.6"

Why Choose the Unitronics US10-B10-B1 UniStream Pro PLC + HMI?

The Unitronics US10-B10-B1 is a powerful all-in-one PLC and HMI controller designed for advanced industrial automation, machine control and process monitoring applications. As part of the UniStream Built-in Pro series, it combines a high-performance PLC CPU with a large 10.1-inch colour touchscreen HMI, delivering powerful control and visualisation capabilities in a compact platform.

The US10-B10-B1 is designed for applications requiring maximum flexibility, as it features no built-in I/O, allowing engineers to configure local and remote expansion modules exactly to application requirements. This modular approach provides a highly scalable solution for OEM machinery, manufacturing systems and complex process automation projects.

Featuring a 10.1-inch WSVGA touchscreen display, advanced communications, integrated web server functionality, SQL client support, VNC remote access and UniCloud connectivity, the US10-B10-B1 provides a future-ready automation platform for Industry 4.0 applications. It supports up to 2,048 I/O points through local and remote expansion modules.

Key Advantages

• Integrated PLC and HMI platform with no separate controller required.
• 10.1-inch colour touchscreen for intuitive operation and monitoring.
• Flexible architecture with no onboard I/O restrictions.
• Supports up to 2,048 expansion I/O points.
• Advanced UniStream Pro functionality.
• Built-in UniCloud connectivity for IIoT applications.
• Supports local and remote I/O expansion.
• Ideal for machine builders and industrial automation engineers.

Key Features

• Unitronics UniStream Built-in Pro PLC + HMI.
• 10.1" 1024 × 600 WSVGA TFT touchscreen.
• No built-in I/O for maximum system flexibility.
• Supports up to 2,048 I/O points via expansion modules.
• Built-in Ethernet communications.
• USB Host and USB Device ports.
• Web Server and SQL Client functionality.
• VNC remote access support.
• FTP Server and FTP Client functionality.
• Audio output support.
• UniCloud-enabled remote monitoring capabilities.
• MicroSD card support for data storage and logging.

Technical Specifications

• Manufacturer: Unitronics
• Series: UniStream Built-in Pro
• Model: US10-B10-B1
• Product type: PLC + HMI controller
• Display size: 10.1 inch TFT touchscreen
• Resolution: 1024 × 600 pixels (WSVGA)
• Colour support: 65,536 colours
• Touchscreen type: Resistive analogue
• Supply voltage: 12 / 24 V DC
• Operating voltage range: 10.2 to 28.8 V DC
• Memory: 1 GB RAM, 6 GB system ROM, 2 GB user ROM
• Built-in I/O: None
• Maximum I/O capacity: Up to 2,048 I/O points
• Communication ports: 1 × Ethernet, 1 × USB Host, 1 × Mini USB Device
• Audio output: 3.5 mm Line Out
• Protection rating: IP66 / NEMA 4X (front panel)
• Operating temperature: -20°C to +55°C
• Mounting type: Panel mounting
• Weight: Approx. 1.08 kg

Build the Exact Automation System You Need

Unlike controllers with fixed onboard I/O, the US10-B10-B1 allows engineers to create highly customised automation systems by selecting only the required I/O modules. This reduces unnecessary hardware costs whilst providing greater flexibility for future expansion.

The UniStream Pro platform offers advanced capabilities including web server access, SQL database connectivity, VNC remote control, FTP communications, UniCloud integration and support for numerous industrial protocols. This makes the controller particularly suitable for connected manufacturing environments and Industry 4.0 applications.

Typical Applications

• OEM machine control systems.
• Industrial automation projects.
• Manufacturing production lines.
• Water and wastewater treatment.
• Packaging machinery.
• Material handling systems.
• Building automation and HVAC control.
• Industry 4.0 and IIoT applications.

Trusted by Automation Engineers Worldwide

Unitronics UniStream Pro controllers are trusted by OEMs, machine builders and industrial automation professionals for delivering powerful control, advanced connectivity and scalable expansion capabilities in demanding automation applications.
