Teknomega MRS3005 Double Earth Bar 2xM10 2x12 2.5-6mm

Why Choose the Teknomega MRS3005 Double Earthing Terminal Bar?

The Teknomega MRS3005 is a compact brass double-connection earthing and neutral terminal bar designed to provide reliable grounding distribution inside industrial switchboards, electrical control panels and machine enclosures. Featuring a 2 × 12 connection configuration, it provides 24 potential conductor connections, allowing two conductors to be connected at each terminal position for organised earth or neutral distribution.

Manufactured from high-conductivity brass, the MRS3005 ensures dependable electrical continuity and long service life. The bar supports dual incoming connections up to 50 mm² and is supplied complete with M4 fixing screws, M10 screws for eyelet terminals and M5 galvanised steel connection screws, making installation quick and secure for professional panel builders.

Key Features

• Double-connection brass earthing terminal bar allowing two conductors per terminal.
• 2 × 12 terminal configuration providing up to 24 possible connections.
• High-conductivity brass bar ensuring reliable electrical grounding.
• Dual incoming terminals accepting cable lugs up to 50 mm².
• Galvanised steel M5 screws for secure conductor termination.
• M4 mounting screws and M10 eyelet screws supplied for installation.
• Numbered terminals for organised wiring and easier maintenance.
• Compact design suitable for electrical cabinets and switchboards.

Technical Specifications

• Manufacturer: Teknomega
• Model: MRS3005
• Reference: MRS 2×12
• Product type: Double-connection brass earthing / neutral terminal bar
• Material: High-conductivity brass (approx. 28% IACS)
• Number of terminals: 12 positions with double connection (24 possible conductors)
• Rated current: approx. 200 A
• Stripped wire size: 2.5 to 6 mm²
• Wire with ferrule: 1.5 to 6 mm²
• Incoming cable capacity: up to 50 mm²
• Tightening torque: approx. 2 Nm
• Dimensions: approx. 144 mm (L) × 19 mm (W) × 9 mm (H)
• Hole diameter: approx. 5.5 mm
• Weight: approx. 0.215 kg
• Fixings supplied: M4 mounting screws, M10 eyelet screws, M5 connection screws

Typical Applications

• Protective earth distribution inside industrial switchboards.
• Neutral or grounding connections in electrical control panels.
• Machine building and OEM electrical installations.
• Electrical cabinets requiring compact earthing distribution.
• Panel building where multiple earth conductors must be organised efficiently.

Trusted by Panel Builders

Teknomega brass earthing and neutral terminal bars are widely used by panel builders and electrical engineers to create safe, organised grounding systems within industrial switchboards and automation panels.
