Teco Inverter E510-203-H1F-220V, 2.2KW, 3.0HP
MPN: E510-203-H1F
Alt. SKU: E510203H1F
Special Price
£455.87
£379.89
Regular Price
£651.24
Why Choose the TECO E510-203-H1F AC Inverter Drive?
The TECO E510-203-H1F is a compact industrial variable frequency drive from the TECO-Westinghouse E510 Compact AC Drive family, designed for dependable three phase motor control in general industrial and OEM automation applications. It delivers stable speed and torque regulation using V/Hz and sensorless vector control, built-in logic and PID functions, integrated diagnostics and Modbus RTU communication for seamless integration with PLCs and HMIs.
The 203 designation identifies this model as a 3 hp (approximately 2.2 kW) constant torque drive configured for 230 V AC three phase supply with a typical rated current of around ~7 A. The H1F suffix indicates a panel mount IP20 / NEMA 1 enclosure with an industrial-grade EMC filter (C2 category), ideal for indoor control cabinets where reduced electromagnetic interference is required.
Key Features
- Rated power: 3 hp (approximately 2.2 kW) constant torque.
- Input supply: 230 V AC three phase, 50/60 Hz.
- Control methods: V/Hz and sensorless vector for flexible motor control.
- Built-in PLC: Integrated logic for standalone automation tasks.
- PID control: Embedded PID loop for process regulation.
- Communications: Modbus RTU over RS-485 included as standard.
- EMC filter: Industrial C2 category for reduced interference in panel installations.
- Diagnostics: Real-time status feedback and fault history monitoring.
- Operator interface: Detachable keypad with multi digit display for local setup and monitoring.
- Compact panel design: IP20 / NEMA 1 enclosure suitable for control cabinet use.
Technical Specifications
- Manufacturer: TECO-Westinghouse
- Series: E510 Compact AC Drives
- Model: E510-203-H1F
- Rated output power: 3 hp (approx 2.2 kW)
- Rated output current: ~7 A constant torque
- Input voltage: 230 V AC three phase
- Output frequency range: Typically 0 to 599 Hz
- Control modes: V/Hz and sensorless vector
- Communications: Modbus RTU (RS-485)
- EMC filter: Industrial C2 category
- Enclosure rating: IP20 / NEMA 1 (panel mount)
- Protection features: Standard overcurrent, overvoltage and thermal safeguards
Typical Applications
- Pumps and booster systems
- Industrial fans and blowers
- Conveyors and material handling equipment
- HVAC plant and air handling units
- OEM machinery and general automation up to 3 hp
Frequently Asked Questions
What does the 203 designation represent?
The 203 code denotes a 3 hp class variable frequency drive designed for 230 V three phase industrial motor control applications.
What does the H1F suffix indicate?
The H1F suffix indicates a panel mount IP20 / NEMA 1 enclosure with an industrial-grade C2 EMC filter, offering reduced electromagnetic interference compared with standard units.
Is communication included?
Yes. Modbus RTU communication via RS-485 is included as standard for integration with PLCs and HMIs.
Trusted by Engineers
A compact and dependable inverter drive selected for reliable motor control, built-in logic functions and enhanced EMC performance in panel based industrial automation systems.
| Manufacturer Part Number | E510-203-H1F |
|---|---|
| Filter | Filter Included |
| Input Phases | Single Phase |
| KW Rating | 2.2kW |
| Output Phases | Three phase |
| VSD Range | E510 |
| Manufacturer | TECO |
| Alternative Product SKU | E510203H1F |
