Why Choose the Partex RPU3010 Blue Pre-Insulated Ring Terminal?
The Partex RPU3010 Blue Pre-Insulated Ring Terminal is engineered for dependable, high-integrity cable termination in industrial, automotive, and panel wiring. Designed for 1.5–2.5 mm² (16–14 AWG) multi-stranded copper conductors and large 70 mm studs, this terminal provides robust connections in even the most demanding environments.
Key Takeaways
Accepts 1.5–2.5 mm² (16–14 AWG) copper conductors
Designed for 70 mm studs
Blue PVC insulation for safety and visual identification
Rated up to 600V; temperature range: -20°C to +75°C
Supplied in packs of 100 units
Frequently Asked Questions About the Partex RPU3010 Blue Pre-Insulated Ring Terminal
Partex RPU3010 Blue Pre-Insulated Ring Terminal Overview
The RPU3010 is ideal for large-stud terminations in switchgear, control cabinets, heavy vehicles, and automation equipment. Its insulated barrel ensures safe, repeatable crimps and protects against accidental shorts. Blue insulation allows for instant wire size identification on site.
Speed & Safety Benefits
Quick installation: Pre-insulated for efficient, repeatable crimping
Clear identification: Blue insulation for fast wire range checks
Improved safety: Insulation protects against shorts and accidental contact
Key Features of the Partex RPU3010 Blue Pre-Insulated Ring Terminal
Product Type: Pre-insulated ring terminal
Conductor Size: 1.5–2.5 mm² (16–14 AWG)
Stud Size: 70 mm
Insulation Material: Blue PVC
Voltage Rating: 600V
Operating Temperature: -20°C to +75°C
Pack Size: 100 units
The RPU3010 is designed for 1.5–2.5 mm² (16–14 AWG) multi-stranded copper conductors.
Strip the cable, insert it into the barrel, and crimp with a suitable hand or ratchet tool. Place the ring on a 70 mm stud and tighten securely.
Yes, this terminal is widely used in industrial control panels, vehicle wiring, and heavy equipment.
Partex offers a full range of stud sizes and right-angled versions. See the Partex catalog for details.
Supplied in packs of 100 units.
Choose the Partex RPU3010 Blue Pre-Insulated Ring Terminal for robust, safe, and reliable large-stud cable terminations.
