ABB S202M-B63 MCB - S200P - 2P - B - 63A

Why Choose the S202M-B63 [2CDS272001R0635]

System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.

Technical Specification

• Function: Current limiting miniature circuit breaker with thermal and electromechanic tripping mechanisms for overload and short circuit protection.
• Voltage Rating: Up to 440 V AC; maximum operating voltage UL/CSA 480Y/277 V AC, 125 V DC.
• Current Rating: Rated currents up to 63 A; this model rated at 63 A.
• Contact Configuration: 2 poles (2P) with red ON / green OFF position indication.
• Breaking Capacity: Ultimate breaking capacity up to 25 kA at 230 V AC and 15 kA at 400/440 V AC.
• Terminal Type and Size Range: Screw terminals; flexible cables 0.75 to 25 mm², rigid cables 0.75 to 35 mm²; busbar 10/10 mm².
• Mechanical and Electrical Endurance: 20,000 operating cycles mechanical; 10,000 - 20,000 AC cycles electrical.
• Insulation and Dielectric Strength: Dielectric test voltage 2 kV (50/60 Hz, 1 min); actuator insulation group II, sealable.
