FE01D01000 - CYLINDRICAL FUSE 10X38 GPV 10A

Why Choose the FE01D01000?

The Lovato FE01D01000 is a 10x38mm fuse engineered for photovoltaic DC protection. Rated 10A at up to 1000V DC and offering a 30kA breaking capacity, it safeguards PV strings and DC circuits from overcurrents. Built to IEC/EN 60269-6, this compact FE series device ensures dependable performance in demanding solar environments.

Designed specifically as a fuse for PV applications in the 10x38mm format, it operates reliably from -20 to +70 °C and up to 3000 m altitude. With DC-only operation, no light indicator, and just 8 g weight, the FE series provides straightforward, compliant protection for solar combiner panels, inverters’ DC inputs, and other renewable DC circuits.

Key Benefits

• High 30kA breaking capacity at 1000V DC for robust fault interruption.
• 10A IEC rated current ensures precise overcurrent protection in PV strings.
• Complies with IEC/EN 60269-6 for photovoltaic applications and safety.
• Wide -20 to +70 °C operating temperature for outdoor solar environments.
• Compact 10x38mm format suits space-constrained DC installations.
• DC-only design optimised for photovoltaic circuits up to 1000V.
• Lightweight 8 g fuse simplifies handling and integration.

Technical Specification

• Product type designation: FE
• Operating voltage type: DC
• Operating temperature: -20 to +70 °C
• Storage temperature: -40 to +80 °C
• Max altitude: 3000 m
• Weight: 8 g

What’s Included

• 1 x Lovato FE01D01000 PV fuse (10x38mm, 10A, 1000V DC)
• Technical datasheet (downloadable)
• Protective packaging for safe transit

Applications

• Photovoltaic string and array overcurrent protection
• DC combiner boxes in solar installations
• Protection of inverters’ DC input circuits
• General DC protection in renewable energy systems up to 1000V

Safety note: Install and replace only when the circuit is isolated. Use within the stated DC ratings and standards, and have a qualified electrician perform all work.
