FE01D00800 - CYLINDRICAL FUSE 10X38 GPV 8A
MPN: FE01D00800
Special Price
£20.22
£16.85
Regular Price
£33.70
Why Choose the FE01D00800?
Lovato’s FE01D00800 is a Fuses for PV applications - 10x38mm DC fuse engineered for reliable protection in photovoltaic circuits. Rated 1000VDC at 8A with a robust 30kA breaking capacity, it safeguards PV systems against overcurrent faults. The compact 10x38mm format integrates easily, and with no light indicator it delivers straightforward, maintenance-free operation across new installations and retrofits focused on dependable DC protection.
Built on Lovato’s FE series, this DC-rated fuse meets IEC/EN 60269-6 for dedicated photovoltaic protection. It operates from -20 to +70 °C, withstands storage from -40 to +80 °C, and is suitable for sites up to 3000 m altitude. Lightweight at just 8 g, it fits neatly in panels and enclosures where 10x38 mm PV fuses are specified for reliable, standards-compliant performance.
Key Benefits
- 1000 V DC rating for modern photovoltaic protection requirements.
- 8 A IEC rated current for precise circuit coordination.
- 30 kA breaking capacity at 1000 V DC enhances safety.
- Conforms to IEC/EN 60269-6 for PV fuse applications.
- Compact 10x38 mm format for space-efficient installations.
- Operates -20 to +70 °C; reliable across varied climates.
- No light indicator for simple, robust, maintenance-free design.
- Suitable up to 3000 m installation altitude.
Technical Specification
- Product type designation: FE
- Operating voltage type: DC
- Operating temperature: -20 to +70 °C
- Storage temperature: -40 to +80 °C
- Max altitude: 3000 m
- Weight: 8 g
What’s Included
- 1 x Lovato FE01D00800 PV fuse, 10x38mm, 8 A, 1000 VDC
- Manufacturer datasheet (digital download)
- Standard protective packaging
Applications
- Photovoltaic DC circuits up to 1000 V
- PV combiner and distribution panels using 10x38 mm fuses
- Inverter DC side protection where 8 A fuses are specified
- General PV installations requiring IEC/EN 60269-6 compliant DC fuses
Frequently Asked Questions
What are the rated voltage and current?
It is IEC rated at 1000 V DC and 8 A.
What is the breaking capacity?
The fuse has a 30 kA breaking capacity at 1000 V DC.
Is this fuse suitable for photovoltaic applications?
Yes. It is designed for PV use and complies with IEC/EN 60269-6.
Does this fuse have a light indicator?
No. The FE01D00800 has no light indicator.
What are the operating conditions?
It operates from -20 to +70 °C and up to 3000 m altitude.
Safety note: Always isolate DC sources before replacing fuses. Installation must be carried out by a qualified person, using the correct 8 A, 1000 V DC rating and observing IEC/EN 60269-6.
| Manufacturer Part Number | FE01D00800 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85361010 |
| Barcode | 8013975187081 |
