FE01D00600 - CYLINDRICAL FUSE 10X38 GPV 6A

Why Choose the FE01D00600?

The Lovato FE01D00600 is a 10x38mm photovoltaic fuse rated 6 A at 1000 V DC. This FE series fuse-link delivers a 30 kA breaking capacity to clear DC faults quickly and limit equipment damage. As a Fuses for PV applications - 10x38mm device, it provides dependable overcurrent protection for PV string circuits and other DC components within solar power systems.

Built for photovoltaic duty, the FE series complies with IEC/EN 60269-6 and uses a DC operating voltage type. It operates from -20 to +70 °C, with storage from -40 to +80 °C, and a maximum altitude of 3000 m. The compact 8 g design in a 10x38 mm format includes no light indicator, simplifying specification and maintenance.

Key Benefits

• 1000 V DC rating supports high-voltage photovoltaic string protection.
• 6 A current rating for precise overcurrent protection at string level.
• 30 kA breaking capacity ensures rapid, dependable fault interruption.
• Compliant with IEC/EN 60269-6 for dedicated PV fuse applications.
• Wide operating temperature from -20 to +70 °C across typical conditions.
• Compact 10x38 mm format suits space-constrained DC installations.
• DC operating voltage type optimised for photovoltaic applications.

Technical Specification

• Product type designation: FE
• Operating voltage type: DC
• Operating temperature: -20 to +70 °C
• Storage temperature: -40 to +80 °C
• Max altitude: 3000 m
• Weight: 8 g

What’s Included

• 1 x Lovato FE series 10x38 mm PV fuse, 6 A, 1000 V DC
• Product datasheet (PDF) for specifications
• Standard manufacturer packaging

Applications

• Protection of photovoltaic string circuits up to 1000 V DC
• DC protection in PV combiner and junction boxes
• Overcurrent protection in solar DC distribution panels
• Fault clearing in balance-of-system PV DC circuits

Safety note: Always isolate and verify the circuit is de-energised before installation or replacement. Select fuses by voltage, current, and size, and use only in suitable 10x38 mm DC holders in accordance with IEC standards and local regulations.
