FE01D00400 - CYLINDRICAL FUSE 10X38 GPV 4A

Why Choose the FE01D00400?

Lovato’s FE01D00400 is a dedicated photovoltaic fuse link designed for 10x38mm applications, delivering dependable DC protection at up to 1000 V. Rated at 4 A with a robust 30 kA breaking capacity, it safeguards PV strings and balance-of-system components against overcurrents. Built to the IEC/EN 60269-6 standard, this compact FE series device integrates seamlessly into modern solar installations.

Engineered for reliability in demanding environments, the FE01D00400 operates from -20 to +70 °C and up to 3000 m altitude. The DC-only design suits PV circuits, while its 8 g form factor simplifies handling in fuse carriers sized 10x38mm. With no light indicator to misinterpret, and full IEC compliance, it offers clear, consistent protection across new builds and retrofit solar projects.

Key Benefits

• 30 kA breaking capacity at 1000 V DC for fault interruption.
• 4 A rating suits precise PV string and DC protection.
• IEC/EN 60269-6 compliance for proven safety performance.
• Operates from -20 to +70 °C in varied climates.
• Designed for 10x38mm photovoltaic fuse applications.
• DC operating voltage type tailored to solar systems.
• Lightweight 8 g component simplifies installation.
• Qualified for use up to 3000 m altitude.

Technical Specification

• Product type designation: FE
• Operating voltage type: DC
• Operating temperature: -20 to +70 °C
• Storage temperature: -40 to +80 °C
• Max altitude: 3000 m
• Weight: 8 g

What’s Included

• 1 x Lovato FE series 10x38mm PV fuse, 4A (FE01D00400)
• Product datasheet (download link provided)
• Manufacturer packaging

Applications

• PV string overcurrent protection within solar arrays.
• Combiner boxes and DC distribution in photovoltaic systems.
• DC input protection for solar inverters.
• Protection within PV DC isolator circuits.

Safety note: Install and replace only by a qualified electrician. Isolate DC circuits before work and use in correctly rated 10x38mm PV holders. Follow IEC/EN 60269-6 and the manufacturer’s instructions.
