FE01D00200 - CYLINDRICAL FUSE 10X38 GPV 2A

Why Choose the Lovato FE01D00200 Photovoltaic Fuse?

The Lovato FE01D00200 is a high-performance gPV cylindrical fuse specifically designed to protect photovoltaic (PV) DC systems. Engineered for use with 10 × 38 mm fuse holders, it provides reliable protection against overloads and short circuits in solar power installations, helping safeguard PV strings, combiner boxes and associated DC equipment.

With a 2 A rated current, 1000 V DC operating voltage and an impressive 30 kA breaking capacity, the FE01D00200 delivers dependable fault protection for modern photovoltaic applications. Manufactured to IEC standards, it offers long-term reliability in demanding outdoor and renewable energy environments.

Designed for seamless compatibility with Lovato PV fuse holders, the FE01D00200 provides fast fault interruption while helping maximise the safety, efficiency and reliability of solar energy systems.

Key Advantages

• Designed specifically for photovoltaic DC applications.
• 2 A rated current.
• 1000 V DC rated voltage.
• 30 kA breaking capacity for reliable fault protection.
• gPV protection characteristic for solar installations.
• Suitable for 10 × 38 mm fuse holders.
• Manufactured to IEC/EN 60269-6.
• Reliable protection for PV strings and combiner boxes.

Key Features

• Lovato Electric FE series.
• 10 × 38 mm cylindrical fuse.
• 2 A rated current.
• 1000 V DC rated voltage.
• 30 kA breaking capacity.
• gPV utilisation category.
• Designed for photovoltaic applications.
• Ceramic fuse construction.
• No visual indicator.
• Compatible with Lovato PV fuse holders.

Technical Specifications

• Manufacturer: Lovato Electric
• Series: FE
• Model: FE01D00200
• Product type: Photovoltaic cylindrical fuse
• Fuse size: 10 × 38 mm
• Rated current: 2 A
• Rated voltage: 1000 V DC
• Breaking capacity: 30 kA
• Utilisation category: gPV
• Voltage type: DC
• Compliance: IEC/EN 60269-6
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +80°C
• Maximum installation altitude: 3000 m
• Weight: Approx. 8 g

Reliable Protection for Solar Power Systems

The Lovato FE01D00200 is engineered specifically for protecting photovoltaic circuits against overloads and short circuits. Its gPV characteristic ensures safe interruption of DC fault currents, helping protect solar modules, inverters and associated equipment throughout the lifetime of the installation.

Whether installed in combiner boxes, PV arrays or renewable energy distribution equipment, the FE01D00200 provides dependable protection that supports the safe operation of modern solar power systems.

Typical Applications

• Photovoltaic string protection.
• Solar combiner boxes.
• DC disconnect systems.
• Renewable energy installations.
• PV inverter protection.
• Industrial solar power systems.

Trusted by Solar Installation Professionals Worldwide

Lovato Electric photovoltaic fuses are trusted by renewable energy installers, panel builders and electrical engineers for dependable DC circuit protection, high breaking capacity and reliable long-term performance in solar power systems.
