ABB S201-C3NA MCB - S200P - 1+NP - C - 3A
MPN: 2CDS251103R0034
Alt. SKU: S201-C3NA
Special Price
£34.76
£28.97
Regular Price
£63.20
Why Choose the S201-C3NA [2CDS251103R0034]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Current limiting miniature circuit breaker with thermal and electromechanical tripping for overload and short circuit protection.
- Rated Voltage & Current: Up to 400 V AC and 63 A.
- Contact Configuration: 1P+N with neutral terminals on right.
- Breaking Capacity: Up to 20 kA at 133 V AC, 10 kA at 230/400 V AC.
- Terminal Type & Capacity: Screw terminals; flexible and rigid cables from 0.75 to 35 mm², busbar 10/10 mm².
- Mechanical & Electrical Endurance: Rated for 20,000 mechanical and electrical cycles.
- Insulation & Dielectric Strength: Dielectric test voltage 2 kV (50/60 Hz for 1 min); actuator material insulation group II.
- Contact Position Indicator: Red ON / Green OFF for easy status identification.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What are the tripping mechanisms used in the S200 miniature circuit breakers?
The S200 miniature circuit breakers utilise a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection.
What is the maximum breaking capacity of the S200 MCBs?
The S200 MCBs have a breaking capacity of up to 20 kA at 133 V AC and 10 kA at 230/400 V AC.
What is the rated current and voltage for the S200 circuit breakers?
The S200 circuit breakers are rated for a maximum voltage of up to 400 V AC and a maximum current of 63 A.
What types of cables can be connected to the S200 MCBs?
The S200 MCBs can accommodate flexible and rigid cables ranging from 0.75 to 35 mm², as well as a busbar of 10/10 mm².
Can auxiliary contacts be mounted on the S200 MCBs?
Yes, a bottom-fitting auxiliary contact can be mounted on the S200 MCBs, allowing for a space saving of 50%.
What is the mechanical and electrical endurance of the S200 MCBs?
The S200 MCBs are rated for 20,000 mechanical and electrical cycles.
Are the S200 MCBs compliant with any standards?
Yes, all MCBs in the S200 range comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS251103R0034 |
|---|---|
| Amperage | 3A |
| Number of Poles | 1 Pole + N |
| Manufacturer | ABB |
| Alternative Product SKU | S201-C3NA |
| Barcode | 4016779531702 |
