ABB f204bs-125/0.5 4p rcd 125a 500ma
MPN: 2CSF204823R4950
Alt. SKU: F204 B S-125/0.5-L
Special Price
£4,632.30
£3,860.25
Regular Price
£7,720.50
Why Choose the F204 B S-125/0.5-L [2CSF204823R4950]
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications. This product is particularly suitable for the protection against smooth d.c. earth fault currents.
Technical Specification
- Function: Residual Current Circuit Breaker (RCCB) Type B for protection against earth fault currents including smooth DC faults.
- Rated Voltage (Ut): 150–250 V.
- Maximum Surge Current: 5 kA.
- Contact Configuration: 4 poles (4P), selective operating characteristic.
- Electrical Endurance: 2000 cycles.
- Mechanical Endurance: 5000 cycles.
- Terminal Type & Capacity: Screw terminals; busbar 10 mm², rigid and flexible 35 mm² max; solid-core up to 50 mm².
- Tightening Torque: 3 N·m.
- Insulation: Housing and actuator insulation groups I - II (RAL 7035 / RAL 5015).
- Additional Features: Signal/auxiliary contact and motor operating device options available.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the RCCB F200 series?
The RCCB F200 series provides protection against earth fault currents, including smooth DC faults.
What is the rated voltage for the RCCB F200 series?
The rated voltage for the RCCB F200 series is between 150–250 V.
What is the maximum surge current rating?
The maximum surge current rating is 5 kA.
What is the terminal capacity for the RCCB F200 series?
The terminal type is screw terminals with a busbar capacity of 10 mm², rigid and flexible conductors up to 35 mm², and solid-core conductors up to 50 mm².
How many poles does the RCCB F200 series have?
The RCCB F200 series features a 4-pole (4P) configuration.
What is the tightening torque for the terminals?
The tightening torque for the terminals is 3 N·m.
Are there any additional features available?
Yes, options for signal/auxiliary contacts and motor operating devices are available.
| Manufacturer Part Number | 2CSF204823R4950 |
|---|---|
| Amperage | 125A |
| Number of Poles | 4 Pole |
| Manufacturer | ABB |
| Alternative Product SKU | F204 B S-125/0.5-L |
| Barcode | 8012542731238 |
| Product Lead Time | Delivery 3/4 Days |
