ABB S203M-D16 MCB - S200M - 3P - D - 16A
MPN: 2CDS273001R0161
Alt. SKU: S203M-D16
Special Price
£66.77
£55.64
Regular Price
£121.39
Why Choose the S203M-D16 [2CDS273001R0161]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanic tripping for overload and short circuit protection.
- Voltage Rating: Up to 440 V AC.
- Current Rating: 16 A.
- Contact Configuration: 3 poles (3P).
- Breaking Capacity: 25 kA at 230 V AC, 15 kA at 400/440 V AC.
- Terminal Type: Screw terminals, compatible with busbar 10/10 mm² and cables 0.75–35 mm².
- Mechanical and Electrical Endurance: 20,000 cycles each.
- Insulation and Test Voltages: Rated dielectric voltage 2 kV (50/60 Hz, 1 min).
- Connection Torque: 2.8 N·m standard, 18 in·lb UL/CSA.
- Indicator: Red ON / Green OFF contact position indication.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What are the tripping mechanisms used in the S200M miniature circuit breakers?
The S200M miniature circuit breakers utilise a delayed thermal tripping mechanism for overload protection and an electromechanic tripping mechanism for short circuit protection.
What is the maximum breaking capacity of the S200M circuit breakers?
The maximum breaking capacity is up to 10 kA at 230/400 V AC.
What is the current rating range for the S200M series?
The S200M series has rated currents available up to 63 A.
What types of terminal connections are compatible with the S200M circuit breakers?
The S200M circuit breakers feature screw terminals compatible with busbars of 10/10 mm² and cables ranging from 0.75 to 35 mm².
Can auxiliary contacts be mounted on the S200M circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200M to save 50% space.
What standards do the S200M circuit breakers comply with?
All MCBs in the S200M range comply with IEC/EN 60898-1 and IEC/EN 609 47-2. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS273001R0161 |
|---|---|
| Amperage | 16A |
| Number of Poles | 3 Pole |
| Trip Curve Type | Type B 10KA |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203M-D16 |
| Barcode | 4016779601030 |
