ABB S201M-C25NA MCB - S200M - 2P - C - 25A
MPN: 2CDS271103R0254
Alt. SKU: S201M-C25NA
Special Price
£33.05
£27.54
Regular Price
£60.08
Why Choose the S201M-C25NA [2CDS271103R0254]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanical tripping for overload and short-circuit protection.
- Rated Voltage: Up to 400 V AC (230/400 V).
- Rated Current: 25 A.
- Contact Configuration: 1P+N, single pole plus neutral.
- Breaking Capacity: 15 kA at 230/400 V AC, 25 kA at 133 V AC.
- Terminal Type and Capacity: Screw terminals; Busbar up to 10 mm², flexible/rigid conductors 0.75 to 35 mm².
- Mechanical and Electrical Endurance: 20,000 cycles each.
- Dielectric Test Voltage: 2 kV at 50/60 Hz for 1 minute.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the S200M miniature circuit breakers?
The S200M miniature circuit breakers provide overload and short-circuit protection through thermal and electromechanical tripping mechanisms.
What are the available configurations for the S200M?
The S200M is available in configurations of 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the maximum breaking capacity of the S200M?
The maximum breaking capacity is up to 10 kA at 230/400 V AC.
What is the rated current for the S200M circuit breakers?
The S200M circuit breakers have a rated current of up to 63A.
What is the cable capacity for the terminals of the S200M?
The screw terminals can accommodate busbars up to 10 mm² and flexible/rigid conductors from 0.75 to 35 mm².
What standards do the S200M comply with?
All MCBs of the S200M range comply with IEC/EN 60898-1 and IEC/EN 60947-2. See the manufacturer's data sheet for standards and approvals.
How many cycles can the S200M withstand mechanically and electrically?
The S200M has a mechanical and electrical endurance of 20,000 cycles each.
| Manufacturer Part Number | 2CDS271103R0254 |
|---|---|
| Amperage | 25A |
| Number of Poles | 2 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S201M-C25NA |
| Barcode | 4016779550178 |
