ABB f202 a s-100/0,3 2 pole rcd 100a 300ma
MPN: 2CSF202201R3900
Alt. SKU: F202 A S-100/0.3
Special Price
£202.30
£168.58
Regular Price
£337.15
Why Choose the F202 A S-100/0.3 [2CSF202201R3900]
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
Technical Specification
- Function: Residual Current Circuit Breaker (RCCB) Type A, selective operating characteristic.
- Rated Voltage: 110-254 V AC test voltage, maximum operating voltage 277 V AC (UL/CSA).
- Number of Poles: 2 poles.
- Maximum Surge Current: 5 kA.
- Terminal Type: Screw terminals suitable for busbar (10 mm²), rigid and flexible cables (35 mm²).
- Connecting Capacity: Multi-wired 0-35 mm² and solid-core 35 mm² conductors.
- Electrical Endurance: 10,000 cycles.
- Mechanical Endurance: 20,000 cycles.
- Wire Stripping Length: Top 12.7 mm, Bottom 14.9 mm.
- Tightening Torque: 2.8 N·m.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the RCCB F200 series?
The RCCB F200 series provides protection against fault current to earth, ensuring safety for both people and installations.
What is the rated voltage for the RCCB F200 series?
The rated voltage is 110-254 V AC, with a maximum operating voltage of 277 V AC (UL/CSA).
How many poles does the RCCB F200 series have?
The RCCB F200 series is available in a 2-pole configuration.
What is the maximum surge current rating?
The maximum surge current rating is 5 kA.
What types of cables can be connected to the RCCB F200 series?
The terminal type is suitable for screw terminals for busbar (10 mm²), rigid and flexible cables (35 mm²), with a connecting capacity for multi-wired 0-35 mm² and solid-core 35 mm² conductors.
What are the electrical and mechanical endurance ratings?
The electrical endurance is rated for 10,000 cycles, while the mechanical endurance is rated for 20,000 cycles.
What is the required wire stripping length for installation?
The wire stripping length is 12.7 mm for the top and 14.9 mm for the bottom.
| Manufacturer Part Number | 2CSF202201R3900 |
|---|---|
| Amperage | 100A |
| Number of Poles | 2 Pole |
| Trip Curve Type | Type B 10KA |
| HS Code | 85363030 |
| Country of Manufacture | Italy |
| Manufacturer | ABB |
| Alternative Product SKU | F202 A S-100/0.3 |
| Barcode | 8012542916109 |
