1SCA149066R1001 ABB OTDC100E33 6 Pole 1000VDC 100A Switch Disconnector
MPN: 1SCA149066R1001
Alt. SKU: OTDC100E33
Why Choose the OTDC100E33 [1SCA149066R1001]
The OTDC100E33 is a DC switch-disconnector rated at 100A and 1000V IEC, designed for base mounting installations. Please note that the handle and shaft are supplied separately, allowing for flexible configuration to suit specific application requirements. This robust device ensures reliable isolation and switching in DC electrical systems, meeting industry standards for safety and performance.
Technical Specification
- Function: DC Switch-disconnector for photovoltaic applications.
- Rated Operational Voltage: 1000 V DC.
- Rated Operational Current: 100 A (DC-21B utilisation category).
- Contact Configuration: Triple circuit, 6 poles (3 circuits x 2 poles).
- Rated Insulation Voltage (Ui): 1500 V.
- Rated Impulse Withstand Voltage (Uimp): 12 kV.
- Degree of Protection: Front IP20.
- Terminal Type: Lug terminals, 19.5 mm width.
- Mounting Type: Base mounting.
- Positive Opening Torque: 5 to 8 N·m (direct opening action).
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the OTDC100E33?
The OTDC100E33 is a DC switch-disconnector designed for photovoltaic applications.
What is the rated operational voltage and current?
The rated operational voltage is 1000 V DC, and the rated operational current is 100 A (DC-21B utilisation category).
What is the contact configuration of the switch?
The switch has a triple circuit contact configuration with 6 poles (3 circuits x 2 poles).
What is the degree of protection for this product?
The degree of protection is IP20 for the front of the device.
How is the OTDC100E33 mounted?
The OTDC100E33 is designed for base mounting.
What type of terminals does the switch use?
The switch features lug terminals with a width of 19.5 mm.
What are the rated insulation and impulse withstand voltages?
The rated insulation voltage is 1500 V, and the rated impulse withstand voltage is 12 kV.
| Alternative Product SKU | OTDC100E33 |
|---|---|
| Manufacturer Part Number | 1SCA149066R1001 |
| Manufacturer | ABB |
| Barcode | 6417019786421 |
| Number of Poles | 6 pole |
| Number of switches | 1 |
| Rated operating voltage | 1000 |
| Device construction | Built-in device fixed built-in technique |
| Type of control element | Other |
| Rated permanent current Iu | 100A |
| Voltage | 1000VDC |
| Degree of protection (IP) | IP20 |
| Nema Rating | 1 |
| Type of electric connection | Bolt connection |
| Packed Quantity | 1 |
| Height | 255mm |
| Width | 190mm |
| Depth | 98mm |
| HS Code | 85365080 |
| Country of Manufacture | Finland |
