1SCA141151R1001 ABB OTDC100E12 3 Pole 1000VDC 100A Switch Disconnector
MPN: 1SCA141151R1001
Alt. SKU: OTDC100E12
Why Choose the OTDC100E12 [1SCA141151R1001]
The OTDC100E12 DC switch-disconnector is rated for 100 A at 1000 V DC in accordance with IEC standards. It features a base mounting design and includes a terminal bolt kit for secure connections. Please note that the handle and shaft are supplied separately and must be ordered in addition to the unit. This switch-disconnector is suitable for reliable isolation in DC electrical systems.
Technical Specification
- Function: DC Switch-disconnector for photovoltaic applications.
- Rated Operational Voltage: 1000 V DC.
- Rated Operational Current: 100 A (DC-21B).
- Contact Configuration: 3 poles (3P).
- Rated Insulation Voltage: 1500 V.
- Rated Impulse Withstand Voltage: 12 kV.
- Degree of Protection: Front IP20.
- Terminal Type and Size: Lug terminals, 19.5 mm width.
- Mounting Type: Base mounting, shaft and handle ordered separately.
- Thermal Current: 100 A at 40 °C.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the OTDC100E12?
The OTDC100E12 is a DC switch-disconnector designed for photovoltaic applications.
What is the rated operational voltage and current?
The rated operational voltage is 1000 V DC and the rated operational current is 100 A (DC-21B).
What is the contact configuration of the switch?
The switch has a 3-pole contact configuration (3P).
What are the mounting options for the OTDC100E12?
The OTDC100E12 is designed for base mounting, with the handle and shaft needing to be ordered separately.
What is the degree of protection for this product?
The degree of protection is IP20 for the front of the device.
What type of terminals does the OTDC100E12 use?
It uses lug terminals with a width of 19.5 mm.
What are the thermal current specifications?
The thermal current rating is 100 A at 40 °C.
| Alternative Product SKU | OTDC100E12 |
|---|---|
| Manufacturer Part Number | 1SCA141151R1001 |
| Manufacturer | ABB |
| Barcode | 6417019687957 |
| Number of Poles | 3 Pole |
| Number of switches | 1 |
| Rated operating voltage | 1000 |
| Device construction | Built-in device fixed built-in technique |
| Type of control element | Other |
| Rated permanent current Iu | 100A |
| Voltage | 1000VDC |
| Degree of protection (IP) | IP20 |
| Nema Rating | 1 |
| Type of electric connection | Bolt connection |
| Packed Quantity | 1 |
| Height | 176mm |
| Width | 151mm |
| Depth | 74mm |
| HS Code | 85365080 |
| Country of Manufacture | Finland |
